Chapter 1 IntroductionCP2000
1-25
690V
Frame H
H2: VFD4000CP63A-21; VFD4500CP63A-21; VFD5600CP63A-21; VFD6300CP63A-21
S1
S2
S3
W
W1
D
D1
H
S4
See Detail A
DETAIL A
(MOUNTING HOLE)
W2
W4
W3
W5
D2
D3 D3
D4
D5
See Detail B
DETAIL B
(MOUNTING HOLE)
S5
H1
H2
H3 H3
3
2
1
3
2
1
1
1
3
3
Figure 1-31
Unit: mm [inch]
Frame W W1 W2 W3 W4 W5 H H1 H2 H3 D D1 D2
H2
700.0
[27.56]
630.0
[24.80]
800.0
[31.50]
500.0
[19.69]
630.0
[24.80]
760.0
[29.92]
1745.0
[68.70]
1715.0
[67.52]
74.5
[2.93]
137.0
[5.39]
404.0
[15.91]
51.0
[2.01]
68.0
[2.68]
Frame D3 D4 D5 S1 S2 S3 S4 S5 Φ1 Φ2 Φ3
H2
137.0
[5.39]
103.0
[4.06]
204.0
[8.03]
26.5
[1.04]
13.0
[0.51]
14.0
[0.55]
25.0
[0.98]
13.0
[0.51]
22.0
[0.87]
34.0
[1.34]
117.50
[4.63]
See Detail
A
See Detail B
Detail A
(Mounting Hole)
Detail B
(Mounting Hole)
