Chapter 5 Main Circuit TerminalsCP2000
5-18
Frame H
R/L11 U/T1
R/L12 V/T2
S/L22
+1/DC+
S/L21
W/T3T/L32
-/DC-
T/L31
 If you install at Ta 30°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the wire
gauge when using higher temperature wire.
Model Name
Main Circuit Terminals
R/L11, R/L12, S/L21, S/L22, T/L31, T/L32,
U/T1, V/T2, W/T3, +1/DC+, -/DC-
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
Max. Wire
Gauge
Min. Wire Gauge
Screw Spec.
and Torque
(±10%)
VFD5600CP43A-00
240mm
2
*4
[500MCM*4]
240mm
2
*4 [500MCM*4]
M12
408kg-cm
[354.1lb-in.]
[39.98Nm]
240mm
2
*4
[500MCM*4]
240mm
2
*2 [500MCM*2]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
VFD6300CP43A-00 240mm
2
*4 [500MCM*4]
240mm
2
*4
[500MCM*4]
240mm
2
*2 [500MCM*2]
VFD5600CP43C-21 240mm
2
*4 [500MCM*4]
240mm
2
*4
[500MCM*4]
240mm
2
*2 [500MCM*2]
VFD6300CP43C-21 240mm
2
*4 [500MCM*4]
240mm
2
*4
[500MCM*4]
240mm
2
*2 [500MCM*2]
