Delta VFD550C43A-00 - Page 214

Chapter 7 Optional AccessoriesC2000 Plus
7-105
Frame H
Assembly for Frame H3 (Conduit Box)
1. Loosen the 3 screws and remove the cover of conduit box H3 as preparation.
Figure 7-112
2. Loosen the screws as below figure shown.
Figure 7-113
