Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-13-1
13 Application Parameters by Industry (appied to 230V / 460V models)
 You can set this parameter during operation
13-00
Industry-Specific Parameter Application
Default: 0
Settings 0: Disabled
1: User-defined Parameter
2: Compressor (IM)
3: Fan
4: Pump
10: Air Handling Unit, AHU
 NOTE: after you select the macro, some of the default values adjust automatically according to
the application selection.
 Group setting 02: Compressor (IM)
The following table lists the relevant compressor application parameters.
Pr. Explanation Settings
00-11 Speed Control Mode 0 (V/F control)
00-16 Duty Selection 0 (Normal load)
00-17 Carrier Frequency Default setting
00-20
Master Frequency Command Source
(AUTO) / Source Selection of the PID
Target
2 (External analog input)
00-21 Operation Command Source (AUTO) 1 (External terminals)
00-22 Stop Method 0 (Ramp to stop)
00-23 Control of Motor Direction 1 (Disable reverse)
01-00 Maximum Operation Frequency Default setting
01-01 Motor 1 Rated / Base Frequency Default setting
01-02 Motor 1 Rated / Base Output Voltage Default setting
01-03 Motor 1 Mid-Point Frequency 1 Default setting
01-04 Motor 1 Mid-Point Voltage 1 Default setting
01-05 Motor 1 Mid-Point Frequency 2 Default setting
01-06 Motor 1 Mid-Point Voltage 2 Default setting
01-07 Motor 1 Minimum Output Frequency Default setting
01-08 Motor 1 Minimum Output Voltage Default setting
01-11 Output Frequency Lower Limit 20 (Hz)
01-12 Acceleration Time 1 20 (s)
01-13 Deceleration Time 1 20 (s)
03-00 Analog Input Selection (AVI) 0 (No function)
03-01 Analog Input Selection (ACI) 1 (Frequency command)
05-01 Full-Load Current For Induction Motor 1 (A) Default setting
05-03 Rated Speed for Induction Motor 1 (Rpm) Default setting
05-04 Number of Poles for Induction Motor 1 Default setting
