Chapter 11 Summary of Parameter SettingsC2000 Plus
11-4
Pr. Parameter Name Setting Range Default
00-01
AC Motor Drive Rated Current
Display
Display by models
Read
only

00-02 Parameter Reset
0: No function
1: Write protection for parameters
5: Return kWh displays to 0
6: Reset PLC (including CANopen Master Index)
7: Reset CANopen Slave index
9: Reset all parameters to defaults
(base frequency is 50 Hz)
10: Reset all parameters to defaults
(base frequency is 60 Hz)
0

00-03 Start-Up Display
0: F (frequency command)
1: H (output frequency)
2: U (user-defined, see Pr.00-04)
3: A (output current)
0

00-04
Content of Multi-Function
Display (User-Defined)
0: Display output current (A) (unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display the motor’s actual output frequency (H.)
(Unit: Hz)
3: Display the drive’s DC bus voltage (v) (Unit: V
DC
)
4: Display the drive’s output voltage (E) (Unit: V
AC
)
5: Display the drive’s output power angle (n)
(Unit: deg)
6: Display the drive’s output power (P) (Unit: kW)
7: Display the motor speed rpm (r) (Unit: rpm)
8: Display the drive’s estimated output torque, motor’s
rated torque is 100% (t) (Unit: %)
9: Display PG feedback (G) (refer to Pr.10-00 and
Pr.10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI analog input terminal signal (1.) (Unit: %)
12: Display ACI analog input terminal signal (2.) (Unit:
%)
13: Display AUI analog input terminal signal (3.) (Unit:
%)
14: Display the drive’s IGBT temperature (i.)
(Unit: °C)
15: Display the drive’s capacitance temperature (c.)
(Unit: °C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
3
