14 Extension Card Parameter
Pr. Parameter Name Setting Range Default

14-00
Extension Card Input Terminal
Selection (AI10)
0: Disable
1: Frequency command
2: Torque command (torque limit under speed mode)
3: Torque compensation command
4: PID target value
5: PID feedback signal
6: Thermistor (PTC / KTY-84) input value
7: Positive torque limit
8: Negative torque limit
9: Regenerative torque limit
10: Positive / negative torque limit
11: PT100 thermistor input value
13: PID compensation value
0

14-01
Extension Card Input Terminal
Selection (AI11)
0

14-08 Analog Input Filter Time (AI10) 0.00–20.00 sec. 0.01

14-09 Analog Input Filter Time (AI11) 0.00–20.00 sec. 0.01
14-10
Analog Input 4–20 mA Signal Loss
Selection (AI10)
0: Disabled
1: Continue operation at the last frequency
2: Decelerate to 0 Hz
3: Stop immediately and display ACE
4: Operate with output frequency lower limit (Pr.01-
11) and displays ANL
0
14-11
Analog Input 4–20 mA Signal Loss
Selection (AI11)
0

14-12
Extension Card Output Terminal
Selection (AO10)
0: Output frequency (Hz)
1: Frequency command (Hz)
2: Motor speed (Hz)
3: Output current (rms)
4: Output voltage
5: DC bus voltage
6: Power factor
7: Power
8: Torque
9: AVI
10: ACI
11: AUI
12: Iq current command
13: Iq feedback value
14: Id current command
15: Id feedback value
18: Torque command
0

14-13
Extension Card Output Terminal
Selection (AO11)
0
