Chapter 3 UnpackingC2000 Plus
3-14
Lift the drive by hooking the lifting hole. It is now ready for installation.
Unpacking 2 (VFDXXXC63B-21)
Remove the eight buckles fixed on the crate with a flat-head screwdriver, see the figure below.
Remove the top cover, take out the EPEs, rubber and the manual.
Figure 3-42
Figure 3-43
Figure 3-44
