Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-04-3

04-24
Position Command 5 (Pulse)

04-26
Position Command 6 (Pulse)

04-28
Position Command 7 (Pulse)

04-30
Position Command 8 (Pulse)

04-32
Position Command 9 (Pulse)

04-34
Position Command 10 (Pulse)

04-36
Position Command 11 (Pulse)

04-38
Position Command 12 (Pulse)

04-40
Position Command 13 (Pulse)

04-42
Position Command 14 (Pulse)

04-44
Position Command 15 (Pulse)
Default: 0
Settings -32767–32767
 Switch the target position through external terminal, that is, set the multi-function input
commands MI1 to MI4 (Pr.02-01 = 1, Pr.02-02 = 2, Pr.02-03 = 3, and Pr.02-04 = 4), and
determine the P2P target position using the multi-step speed.
 Setting method: Target Position = Pr.04-15 × (Pr.10-01*4) + Pr.04-16
Multi-step
Speed Status
P2P Target Position P2P Maximum Speed
0000 0
Pr.11-00
bit8=0
Pr.11-00 bit8=1
0001 Position 1 Pr.04-15 Pr.04-16 Pr.11-43 Pr.04-00
0010 Position 2 Pr.04-17 Pr.04-18 Pr.04-01
0011 Position 3 Pr.04-19 Pr.04-20 Pr.04-02
0100 Position 4 Pr.04-21 Pr.04-22 Pr.04-03
0101 Position 5 Pr.04-23 Pr.04-24 Pr.04-04
0110 Position 6 Pr.04-25 Pr.04-26 Pr.04-05
0111 Position 7 Pr.04-27 Pr.04-28 Pr.04-06
1000 Position 8 Pr.04-29 Pr.04-30 Pr.11-43 Pr.04-07
1001 Position 9 Pr.04-31 Pr.04-32 Pr.04-08
1010 Position 10 Pr.04-33 Pr.04-34 Pr.04-09
1011 Position 11 Pr.04-35 Pr.04-36 Pr.04-10
1100 Position 12 Pr.04-37 Pr.04-38 Pr.04-11
1101 Position 13 Pr.04-39 Pr.04-40 Pr.04-12
1110 Position 14 Pr.04-41 Pr.04-42 Pr.04-13
1111 Position 15 Pr.04-43 Pr.04-44 Pr.04-14

04-50
PLC Buffer 0

04-51
PLC Buffer 1

04-52
PLC Buffer 2

04-53
PLC Buffer 3

04-54
PLC Buffer 4

04-55
PLC Buffer 5

04-56
PLC Buffer 6

04-57
PLC Buffer 7

04-58
PLC Buffer 8

04-59
PLC Buffer 9
