Chapter 5 Main Circuit TerminalsMS300
34
Frame C
Figure 5-10
 If you install at Ta 50°C above environment, use copper wires that have a voltage rating of 600 V
and are temperature resistant to 90°C or above.
 If you install at Ta 50°C environment, use copper wires that have a voltage rating of 600 V and are
temperature resistant to 75°C or 90°C.
 To be UL installation compliant, you must use copper wires when installing. The wire gauge is
based on a temperature resistance of 75°C, in accordance with UL requirements and
recommendations. Do not reduce the wire gauge when using high-temperature resistant wires.
Models
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, DC-,
DC+/+1, +2/B1, B2
Grounding Terminals
Max. Wire
Gauge
Min. Wire
Gauge
Screw Size &
Torque
(±10%)
Max. Wire
Gauge
Min. Wire
Gauge
Screw Size &
Torque
(±10%)
VFD4A8MS11ANSAA
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
M4
20 kg-cm
(17.4 lb-in.)
(1.96 Nm)
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
M4
20 kg-cm
(17.4 lb-in.)
(1.96 Nm)
VFD4A8MS11ENSAA
VFD7A5MS21ANSAA
VFD7A5MS21ENSAA
VFD7A5MS21AFSAA
VFD11AMS21ANSAA
VFD11AMS21ENSAA
VFD11AMS21AFSAA
VFD11AMS23ANSAA
6 mm
2
(10 AWG)
6 mm
2
(10 AWG)
6 mm
2
(10 AWG)
VFD11AMS23ENSAA
VFD17AMS23ANSAA
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
10 mm
2
(8 AWG)
VFD17AMS23ENSAA
VFD5A5MS43ANSAA
2.5 mm
2
(14AWG)
2.5 mm
2
(14 AWG)
2.5 mm
2
(14AWG)
VFD5A5MS43ENSAA
VFD5A5MS43AFSAA
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
VFD9A0MS43ANSAA
4 mm
2
(12 AWG)
4 mm
2
(12 AWG)
4 mm
2
(12 AWG)
VFD9A0MS43ENSAA
VFD9A0MS43AFSAA
VFD4A2MS53ANSAA
2.5 mm
2
(14 AWG)
2.5 mm
2
(14 AWG)
2.5 mm
2
(14 AWG)
VFD6A6MS53ANSAA
4 mm
2
(12 AWG)
4 mm
2
(12 AWG)
4 mm
2
(12 AWG)
Table 5-5
