Appendix A. Modbus ProtocolMS300
792
6. Status monitor read only (22xx): communication station address is Pr.09-00 setting value
Attribute
(Function
Code)
Display output current (A). When current is higher than
655.35, it shifts the decimal as (XXX.X A). The decimal can
refer to High byte of 211F.
Display counter value (c)
Actual output frequency (XXXXX Hz)
Display actual motor speed kW of U, V, W (XXXX.X kW)
Display motor speed in rpm estimated by the drive or
encoder feedback (XXXXX rpm)
Display positive/negative output torque in %, estimated by
the drive (t0.0: positive torque, -0.0: negative torque)
(XXX.X %)
Display PG feedback (see NOTE 1 in Pr.00-04)
PID feedback value after enabling PID function (XXX.XX %)
Display signal of AVI analog input terminal, 0–10 V
corresponds to 0.00–100.00% (1.) (see NOTE 2 in Pr.00-04)
Display signal of ACI analog input terminal, 4–20 mA / 0–10
V corresponds to 0.00–100.00% (2.) (see NOTE 2 in Pr.00-
04)
Display signal of AUI analog input terminal, -10 V–10 V
corresponds to -100.00–100% (3.) (see NOTE 2 in Pr.00-
04)
IGBT temperature of drive power module (XXX.XºC)
Drive capacitance
temperature
The temperature of capacitance (XXX.XºC)
The status of digital input (ON/OFF), refer to Pr.02-12
(see NOTE 3 in Pr.00-04)
The status of digital output (ON/OFF), refer to Pr.02-18
(see NOTE 4 in Pr.00-04)
The multi-step speed that is executing (S)
The co-rresponding
CPU pin status of
digital input
The corresponding CPU pin status of digital input (d.)
(see NOTE 3 in Pr.00-04)
The co-rresponding
CPU pin status of
digital output
The corresponding CPU pin status of digital output (O.)
(see NOTE 4 in Pr.00-04)
Number of actual motor revolution (PG1 of PG card) (P.) it
starts from 9 when the actual operation direction is changed
or the keypad displays at stop is 0. The maximum is 65535
Pulse input frequency (PG2 of PG card) (XXX.XX Hz)
Pulse input position (PG card PG2), the maximum setting is
65535.
