192 - User's Manual
4-4. Graphical Layout and Screen Elements - Search
Search results
Calendar
1
5
2
Configured alarms
3
Trigger types
4
Playback button
Search conditions
The screen elements of the
Playback
window are described as follows:
Item Name Description
1
Search
conditions
The whole panel provides access to search conditions. You can select Devices,
time span, pre-congured alarms, or trigger types.
2
Calendar Shows when the possible time of occurrence of alarms.
3
Congured
alarms
Select the alarms you previously congured on the system.
4
Trigger types There are many trigger types including system event triggers, cyber attacks, DI
/
DO, or the numerous VCA detection triggers.
5
Search results The results are displayed by Alarm name, Time of occurrence, Trigger source,
and the Trigger type.
