INSTRUMENTATION
ON/OFF Switch
ThedryerisequippedwithanON/OFFswitchonthefront
panel. A light signals when the dryer is on.
CONDENSATE DRAIN VALVES
A float operated drain is housed in a metal bowl. It will
automatically drain the condensate.
START-UP/OPERATION
Follow the procedure below to start your dryer. Failure
tofollowtheprescribedstart-upprocedurewillinvalidate
thewarranty.Ifproblemsariseduringstart-up,callyour
distributor.
RefertoSerialNumberTagfordryer
operatingcapacity.Donotexceedrecommendedcapacity.
Drainconnectionsmustbemadebeforethedryercanbe
operated.Thedryersarefullyautomaticandrequireno
auxiliarycontrols.
1. Connectinletandoutletlinestothedryer.Reference
dryerindentationsandinstructiontagforappropriate
inlet and outlet connections.
2. Route drain connections to a condensate separator or
approved collection point.
3. Turntheon/offswitchtoon.Doublecheck
connections.
4. Afterthedryerhasbeenrunningfor30minutes:
a. Checkthaton/offlightedswitchisglowing.If
lightisnotglowing,unplugunitandrefertoField
ServiceGuideforadditionalinformationorcall
your local distributor.
b. Conrmthatcondensateisdischargingfromthe
drain. This can only be done when there is air flow
through the dryer.
ReferenceSerialNumberTagfor
appropriatepowerrequirement/connectionrating.Make
other dryer connections prior to connecting power
source.
The dryer is designed to run continuously. Let the
dryerrunevenwhenthedemandforcompressedairis
interrupted;thedryerwillnotfreezeup.
Operating Check Points
1. Power light is on, light is illuminated.
2. Condensate is discharging properly.
SHUTDOWN
Whenthedryermustbeshutdownformaintenanceor
otherreasons,usethefollowingprocedure:
1. Turnthepoweron/offswitchtooff.
2. Disconnect the main power supply.
Ifmechanicalrepairsaretobemadeorserviceis
performed,venttheinternalpressureofthedryerto
atmospheric pressure. Restart the dryer according to the
start-up instructions.
Disconnectpowersupplyanddepressurize
dryerbeforeservicing.Dismantlingorworkingonany
componentofthecompressedairsystemunderpressure
maycauseequipmentfailureandseriouspersonalinjury.
