Original assembly instructions
Manufacturer
Demag Cranes & Components GmbH
Forststrasse 16
40597 Düsseldorf, Germany
www.demagcranes.com
info@demagcranes.com
Please fill in the following table before first putting the unit into service. This provides you with definitive documentation of your
Demag DRF 200 friction wheel travel drive and important information if you ever have to contact the manufacturer or his rep‐
resentative.
Owner
Where in use
Size
Serial number
Travel drive no.
Year of manufacture
Operating voltage
Control voltage
Frequency
Wiring diagram number
Tab. 1
Further documents are available for sub-assemblies/components in addition to these assembly instructions. If required, the
corresponding documents are supplied or can be ordered separately, even if special designs or additional options differing
from these assembly instructions are ordered.
Documents
1)
Order no.
Technical data/catalogues
Demag DC-Pro 1 - 25 chain hoist
Demag DCS-Pro 1 - 10 chain hoist
203 525 44
KBK classic (steel, powder-coated) 202 976 44
KBK trailing cable 202 617 44
DEL conductor line 202 673 44
DKK conductor line 202 540 44
DCL conductor line 203 387 44
Fittings + C-rail overview 201 752 44
Cellular foam buffer 202 607 44
Operating instructions/component
parts
DC-Pro 1 - 15 chain hoist 214 741 44
DRF current collector bracket 206 630 44
Assembly – Adjustment – Dimensions
ZNA, ZBA, ZBF motors 214 228 44
KBA, KBF motors 214 318 44
Spare parts
DRF 200 friction wheel travel drive 222 572 44
Z 63/Z 71 motor 222 856 44
ZBF 80 motor 222 864 44
KB 71 - 140 motor 217 039 44
Tab. 2
The metric system is used in this document and all figures are shown with a comma as the decimal separator.
1)
The documents can be ordered from the relevant Demag office.
