8.4.3.3 Replacing the brake disc
A)
RD
RD
RD
B)
BU
BU
BU
BU
Fig. 18
Item Designation Item Designation Item Designation
1 Terminal box cover 5 Armature plate 9 End cap
2 Hexagon nuts 6 Brake disc 10 Brake springs
3 Magnet assembly 7 Distance springs 11 Magnet assembly connecting cable
4 Stop plate 8 Collared pin
Tab. 29
44
214 395 44/120914
