C-110-170-200E R11 Page 20
Chassis assembly spare-parts list
Pos: Part no.: Qty.: Description:
1 700510040 4 Screw
2 700530109 1 Cover For El-Box
3 700530107 1 Gasket for El-Box
4
700530005 1
Overload Relay 16A
C-110E 230V 50/60Hz; C-150E 230V 50Hz
700530096 1 Overload Relay 22A
C-150E 230V 50Hz
C-170/200E 220V 50/60Hz
C-110/150E 110V 60Hz
5 700510043 4 Bolt M6 x 35
6 700520026 1 Steel lock Ø14
7
700951546 1m Motor Cable
C-110E 230V 50/60Hz; C-150E 220V/230V 50/60Hz
C-170/200E 230/400/440V 50/60Hz
700951517 1m Motor Cable
C-110E 110V 60Hz
9 700530108 1 Switch Knob
10 700510050 4 Knob Screw Handle
11 700510051 4 Bolt M6 x 18
13
700520060 1 Bracket For Handle
C-110/150/170E
C-200E
14
700530763 1 Fan Cover For Motor
C-110/150E
700530794 1 Fan Cover For Motor
C-170E
700530796 1 Fan Cover For Motor
C-200E
15
700530762 1 Fan Plastic
C-110/150E
700530795 1 Fan Plastic
C-170E
700530797 1 Fan Plastic
C-200E
16 700510228 4 Screw M5 x 35
*
700530002 1 Bearing For Motor
C-110/150E
700530799 1 Bearing For Motor
C-170E
700530800 1 Bearing For Motor
C-200E
17
700530769 1 Motor 24mm Shaft
C-110/150E 230V 50/60Hz
700530793 1 Motor 24mm Shaft
C-110E 110V 60Hz
700530784 1 Motor
24mm Shaft
C-170E 220~460V 50/60Hz
700530785 1 Motor
24mm Shaft
C-200E 220~460V 50/60Hz
18 700530765 1 Capacitor 65uF
C-110/150E
19 N/A - See Auto Start Stop section
20 700520712 1 Motor terminal spacer 20mm for A.S.S
C-110/150E
21 700510010 2 Knob Screw Cabinet
22 700520510 1 Cabinet
23 700530693 1 Gasket for Motor-Pump
25 700510034 4 Spring washer M8
26
700560158 1 Pump complete
C-110E 230V 50Hz
700560002 1
Pump complete
C-170E 220~440V 50/60Hz
C-200E 220V / 440V 60Hz
C-200E 230V / 380~415V 50Hz
700560160 1 Pump complete
C-150E 220V/230V 50/60Hz
28 700510067 1 Washer flat M12
29 700520504 1 Bracket For Castor Wheel
31 700510009 4 Bolt M8 x 16
To Next Page
