Den-Sin C-110E - Pump Assembly Spare-Parts List

C-110-170-200E R11 Page 23
Pump assembly spare-parts list
Pos Part no.: Qty.: Description:
1 700560012 6 O-ring
2 700560013 6 Plug
3
Kit A
6 Complete valve
4 6 O-ring
6
Kit C2 3 Support ring Ø15 C-110/150E 50/60Hz
Kit D2
3
Support ring Ø18
C-170/200E 50/60Hz
7
Kit C2 3 Gasket Ø15 C-110/150E 50/60Hz
Kit D2
3
Gasket Ø18
C-170/200E 50/60Hz
8
Kit C2 3 Piston guide Ø15 C-110/150E 50/60Hz
Kit D2 3 Piston guide Ø18 C-170/200E 50/60Hz
9 700560022 1 Pump body
10
Kit B
1
Cap
11 700560024 1 Circlip Ø52
12
700560025
1
Snap ring
13 700560026 1 Bearing
14 700560027 1 Oil Cap
15 700560028 3 Piston pin
16 Kit B 1 O-ring
17 700560030 6 Screw M6x16
18
700560031
1
Complete cover
19
700560032 3 Connecting rod C-110/150E 50/60Hz
700560213 3 Connecting rod C-170/200E 50/60Hz
20 700560033 3 Guiding piston
21 700560034 3 O-ring
22 700560035 3 Spacer disc
23
Kit C1 3 Piston Ø15 C-110/150E 50/60Hz
Kit D1 3 Piston Ø18 C-170/200E 50/60Hz
24 700560038 3 Piston washer
25 700560039 3 Nut M8
27 700560040 2 O-ring
28 700560041 3 G plug 3/8”
29 700560042 1 Washer
30 Kit B 3 Seal
31
Kit C2 3 Rear piston guide Ø15 C-110/150E 50/60Hz
Kit D2 3 Rear piston guide Ø18 C-170/200E 50/60Hz
32 Kit C2 / D2 3 O-ring
33
Kit C2 3 Gasket Ø15 C-110/150E 50/60Hz
Kit D2 3 Gasket Ø18 C-170/200E 50/60Hz
34 700560049 1 G plug 1/2”
35 700560050 1 Washer
36
700560051
1
Head
37 700560052 8 Washer
38
700560053
8
Screw M6x60
40 700560054 1 Bearing
41 700560055 1 Snap ring
45
700560056 1 Crank shaft 24mm C-150/170E 50/60Hz & C-200E 60Hz
700560161
1
Crank shaft
24mm
C-110E 230V 50Hz
700560058 1 Crank shaft 24mm C-200E 50Hz
46
700560066
1
Key for Ø24mm Shaft
C-110/170E/200E
700560162 1 Key for Ø24mm Shaft C-150E
47 Kit B 1 Seal
- 700560127 1 Oil Indicator
