DAEnetIP2 v2 User Manual
21 Apr 2020
- 14 -
6.3. General Settings
Figure 6.5. General Settings
 Inputs Pull-ups - enable pull-up resistors for P3/P5 ports when they are configured as
digital inputs;
SNMP: cfgPortPullUps.0
 Save Outputs - when checked, each time the relays state is changed, it will be saved in
non-volatile memory (EEPROM), so after reboot/restart it will be restored;
This option should be used with care in dynamic systems because of restriction in maximum write
cycles of the EEPROM (usually 100 000 write/erase cycles).
 Digital Inputs Filter, ms – digital inputs filter constant. The range is from 0 up to 200 ms.
The filter is disabled when its value is set to 0;
This parameter sets a low pass software filter that removes the short-term fluctuations from the
input signal and reduces the effect of occasional spikes. Note that the higher filter constants give a
slower response to changes.
 Analog Inputs Filter, sec – analog inputs filter constant. The range is from 0 up to 30 sec.
The filter is disabled when its value is set to 0;
This parameter sets a low pass software filter that removes the short-term fluctuations from the
input signal and reduces the effect of occasional spikes. Note that the higher filter constants give a
slower response to changes.
