Other features
■ Acclaimed Customization Feature
As with all of DENON’s high-grade A/V receiver, the AVR-1507 lets you adjust para-
meters so that you can customize the performance of the AVR-1507 to suit your own
home theater and enhance operating ease. The adjustments are easy to make via a
dialog format on the fluorescent display on the front panel. These customized fea-
tures are then stored, for each source input and surround mode, in Personal Memory
Plus so constant readjustments are not required.
■ Personal Memory Plus, for Easy Operation
The AVR-1507 includes the Personal Memory Plus function that automatically
remembers the surround mode you last used for each program source, so that you
do not need to select the mode again for that program.
■ 5 Channel/ 7 Channel Stereo Mode
DENON's popular 7 Channel Stereo mode transforms your favorite 2-channel sources
such as CD, tape, stereo radio and stereo video sources into exciting surround
sound, free of delay effects and unnatural artifacts, from all 7 speakers. This 7
Channel Stereo mode was originally developed by DENON to enhance music lovers'
enjoyment with home theater ambience.
■
Night Mode for not disturbing others
■ Front Panel Inputs
■ Front A/B Speaker Terminals
■ High-grade Speaker Terminals (All ch)
■ Remote In/Out Ports
■ Frequency Synthesis Tuning
• 56-Station AM/FM/XM Random Preset Memory Tuning
• Auto Preset Memory
16560606 A Printed in Japan
AVR-1507
Input/Output Terminals For Every A/V System
Audio Inputs
8 Analog Inputs
CD, (TUNER), DVD/VDP, TV/DBS, AUX, VCR, CDR/TAPE, V.AUX(FRONT)
8 Analog EXT. Input
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK L/R, SUBWOOFER
4 Digital Input
OPTICAL X 2
COAXIAL X 2
Audio Outputs
1 Analog PRE OUT Terminals
SUBWOOFER
2 Analog REC OUT Terminals
VCR, CDR/TAPE
Video Inputs
4 Composite Inputs
DVD/VDP, TV/DBS, VCR, V.AUX(FRONT)
3 S-Video Inputs
DVD/VDP, TV/DBS, VCR
3 Component Inputs
DVD/VDP, TV/DBS, VCR
Video Outputs
2 Composite Outputs
VCR, MONITOR
2 S-Video Outputs
VCR, MONITOR
1 Component Output
MONITOR
Specifications
Power Amplifier Section
Rated output *THD figures are power amp stage values.
Front 75 W + 75 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
Center 75 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W (6 ohms, 1 kHz, 0.7 % THD)
Surround 75 W + 75 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
Surround Back
75 W + 75 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
110 W + 110 W (6 ohms, 1 kHz, 0.7 % THD)
Preamplifier Section
Input sensitivity/Impedance CD, DVD/VDP, TV/DBS, VCR, CDR/TAPE, AUX
V.AUX(FRONT) 200 mV/47 kohms
Output level/Load impedance SUBWOOFER 1.2 V/10 kohms
CDR/TAPE, VCR 200 mV/47 kohms
Frequency response 10 Hz - 100 kHz (+1, -3 dB) (Tone Defeat On)
Signal-to-noise ratio 98 dB (IHF-A weighted) (Tone Defeat On)
Tone control Treble: ±12 dB at 10 kHz
Bass: ±12 dB at 100 Hz
FM Section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
AM Section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Power consumption 4.3 A
Dimensions 17-3/32” (W) x 5-25/32” (H) x 16-9/64”(D)
434 (W) x 147 (H) x 417 (D) mm
Weight 11.2 kg, 24 lbs 11 oz
*Design and specifications are subject to change without notice.
*”Dolby”, “Dolby Digital”, “Pro Logic II”, “Dolby Digital EX” and the double-D device are
registered trademarks of Dolby Laboratories Licensing Corporation.
*DTS is registered trademarks of DTS Technology.
*iPod is a trademark of Apple Computer, Inc., registered in the U.S. and other countries.
*©2006 XM Satellite Radio Inc. All rights reserved.
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: 905-475-4085 ca.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive Mahwah, New Jersey 07430 USA
TEL: 201-762-6500 usa.denon.com
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
AVR1507_E3.qxd 06.7.6 7:20 PM Page 2
