Denon AVR-1513 Quick Start Guide

7
ENGLISH FRANÇAIS ESPAÑOL PORTUGUÊS ESPAÑOL NEDERLANDS SVENSKA
7
ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA
3
Use ui to select a speaker, and use
o p to select distance.
Front L / Front R / Center / Subwoofer /
Surround L / Surround R
Select the speaker.
• 0.0ft – 60.0ft : Set the distance.
• The speakers that can be selected differ
depending on the “Speaker Confi g.”
(vpage5) settings.
• Default settings :
Front L / Front R / Center / Subwoofer : 12.0 ft
Surround L / Surround R : 10.0 ft
• Set the difference in the distance between the
speakers to less than 20 ft.
NOTE
Speakers set to “None” in “Speaker Confi g.”
(vpage5) are not displayed.
4
Press ENTER to enter the setting.
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
Step
Front L/R
Center
Subwoofer
Surround L/R
Speaker Setup
1
Use ui to select “Channel Level”,
and then press ENTER.
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
Test Tone Start
Default
Speaker Setup
Enter ReturnENTER
BACK
Test Tone Start
Default
1 Channel Level
2
Press ENTER.
Output test tone.
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
0.0dB
Front L
Center
Front R
Surround R
Surround L
Subwoofer
1 Channel Level
Enter ReturnENTER
BACK
3
Use ui to select a speaker, and use
o p to adjust the sound volume of
each speaker to be equal.
Front L / Center / Front R / Surround R /
Surround L / Subwoofer
Select the speaker.
• –12.0dB – +12.0dB (0.0dB) : Adjust the volume.
• When o is pressed while the subwoofer volume
is set to “–12 dB”, the “Subwoofer” setting
switches to “OFF”.
• When “Channel Level” is adjusted, the adjusted
values are set for all the surround modes. To
adjust the channel level separately for the
different surround modes, use the operation
see vm page 25 “Adjusting the volume of
the speakers“.
NOTE
• Speakers set to “None” in the “Speaker Confi g.”
(vpage5) settings are not displayed.
• When a headphones jack is inserted in the
PHONES jack of this unit, the “Channel Level”
is not displayed.
4
Press ENTER to enter the setting.
Test Tone Start
Default
1 Channel Level
Default
The “Channel Level” settings are
returned to the default settings.
• Yes : Reset to the defaults.
• No : Do not reset to the defaults.
5
Press BACK.
Speaker Config.
Bass Setting
Distance
Channel Level
Crossover Freq.
Test Tone Start
Default
Speaker Setup
Distance (Cont.)
Channel Level
Default settings are underlined.
1.AVR1513E3ENGIMGS00A0214校了後修正.indd71.AVR1513E3ENGIMGS00A0214校了後修正.indd7 2012/02/1420:03:322012/02/1420:03:32

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
