AVR-1604/684 / AVC-1580
D-VIDEO P.W.B. UNIT ( FOR JAPAN MODEL )
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC651 960 0175 200 IC BA7625
IC652,653 963 0083 304 IC BA7626
IC654 963 0120 607 IC BU4053BCF
O651-653 960 0005 105 Transistor KTA1266Y
CAPACITORS GROUP
C651-656 963 9006 476 Electrolytic 4.7uF/50V
C657 963 9005 969 Electrolytic 4700uF/6.3V
C658,659 963 9006 463 Electrolytic 470uF/6.3V
C660-662 963 9006 324 Electrolytic 100uF/10V
C663 960 9003 108 Ceramic 0.022uF/25V
C664 963 9006 324 Electrolytic 100uF/10V
C671,672 963 9006 379 Electrolytic 1uF/50V
C673 960 9003 108 Ceramic 0.022uF/25V
C674 963 9006 324 Electrolytic 100uF/10V
C677-679 963 9004 520 Ceramic 100pF/50V
C681,682 963 9006 379 Electrolytic 1uF/50V
C683 960 9003 108 Ceramic 0.022uF/25V
C684 963 9006 324 Electrolytic 100uF/10V
C687-689 963 9004 520 Ceramic 100pF/50V
C691,692 963 9006 379 Electrolytic 1uF/50V
C693 960 9003 108 Ceramic 0.022uF/25V
C694 963 9006 324 Electrolytic 100uF/10V
C697-699 963 9004 520 Ceramic 100pF/50V
OTHER PARTS GROUP
CN651 963 0097 206 8P connector socket (TUC-P)
JACK601D-603D 963 0085 108 D connector 3
