Denon AVR-1604 Service Manual

32
32
AVR-1604/684 / AVC-1580
R111C,FL,FR,SL,SR 963 9006 269 Metal oxide 0.22 ohm 1W
R118C,FL,FR,SL,SR 963 9006 256 Metal oxide 10 ohm 1W
R119C,FL,FR,SL,SR 963 9006 256 Metal oxide 10 ohm 1W
R135,136 963 0045 203 Winding 0.1 ohm 5W
R141,142 244 2043 982 Metal oxide 0.22 ohm 1W
R148,149 244 2043 982 Metal oxide 0.22 ohm 1W
R151 963 9003 343 Metal film 68ohm 1/4W
R154 963 0043 108 Metal film 2.2 Mohm 1/2W E3,EU,EUT
R179 963 9003 055 Metal film 47 kohm 1/4W (NB)
R181 963 0047 900 Metal film 4.7 kohm 1W
R184 963 9006 256 Metal oxide 10 ohm 1W
R185 963 9005 655 Metal film 22 ohm 1/4W
VR101-105 960 0091 601 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C101C,FL,FR,SL,SR 963 9006 450 Electrolytic 47uF/50V
C102C,FL,FR,SL,SR 963 9006 308 Electrolytic 10uF/50V E3,EU,E2,EK,E2A,E1C,EUT,N
C102C,FL,FR,SL,SR 963 9006 298 Electrolytic 10uF/35V E1K
C103C,FL,FR,SL,SR 963 9003 084 Ceramic 100pF/500V
C104C,FL,FR,SL,SR 963 9003 084 Ceramic 100pF/500V
C105C,FL,FR,SL,SR 960 9003 108 Ceramic 0.022uF/25V
C107C,FL,FR,SL,SR 963 9003 097 Mylar film 0.1uF/250V
C131-135 963 9003 097 Mylar film 0.1uF/250V
C136,137 963 9006 188 Electrolytic 10000uF/63V
C138 963 9006 379 Electrolytic 1uF/50V
C141-143 963 0021 900 Mylar film 0.047uF/100V
C144 963 9003 110 Electrolytic 4700uF/35V
C145 963 9003 123 Electrolytic 1000uF/35V
C146 963 9006 379 Electrolytic 1uF/50V
C148 963 9006 379 Electrolytic 1uF/50V
C150-152 963 0021 900 Mylar film 0.047uF/100V
C153 963 0021 104 Electrolytic 6800uF/16V
C154 963 9006 308 Electrolytic 10uF/50V E3,EU,E2,EK,E2A,E1C,EUT,N
C154 963 9006 298 Electrolytic 10uF/35V E1K
C155 963 0020 202 Ceramic 0.1uF/50V
C157 963 9006 379 Electrolytic 1uF/50V
C158 963 9003 136 Electrolytic 1000uF/25V
C159 963 9006 379 Electrolytic 1uF/50V
C161 963 9006 308 Electrolytic 10uF/50V E3,EU,E2,EK,E2A,E1C,EUT,N
C161 963 9006 298 Electrolytic 10uF/35V E1K
C171 963 9006 324 Electrolytic 100uF/10V
C171A,B,C 963 0020 202 Ceramic 0.1uF/50V
C172,173 963 9005 833 Electrolytic 220uF/6.3V E3,EU,E2,EK,E2A,E1C,EUT,N
C172,173 963 9006 706 Electrolytic 220uF/6.3V E1K
C174 963 9006 308 Electrolytic 10uF/50V E3,EU,E2,EK,E2A,E1C,EUT,N
C174 963 9006 298 Electrolytic 10uF/35V E1K
C175 963 9006 476 Electrolytic 4.7uF/50V
C176 963 9006 379 Electrolytic 1uF/50V
C177 963 9006 379 Electrolytic 1uF/50V
C178 963 9003 149 Electrolytic 330uF/63V E3,EU,E2,EK,E2A,E1C,EUT,N
C178 963 9006 719 Electrolytic 330uF/63V E1K
C181 963 9006 191 Ceramic 4700pF/250V(AC)
C182 963 9006 311 Electrolytic 10uF/100V
C191-198 963 9006 007 Ceramic 2200pF/16V E2,EK,E2A
C198C,FL,FR,SB,SL,SR 963 0024 703 Mylar film 0.01uF/100V E2,EK,E2A
C199FL,FR 963 0024 703 Mylar film 0.01uF/100V E2,EK,E2A
C601 963 9004 520 Ceramic 100pF/50V
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
