AVR-1604/684 / AVC-1580
C602-604 963 9006 434 Electrolytic 47uF/16V
C605,606 963 9006 463 Electrolytic 470uF/6.3V
C607 963 9006 337 Electrolytic 100uF/16V
C611 963 9004 546 Ceramic 0.01uF/16V
C612,613 963 9004 562 Ceramic 0.047uF/50V
OTHER PARTS GROUP
CN601 960 0239 900 13P connector socket (TUC-P)
CN602 963 0097 206 8P connector socket (TUC-P)
CP101 960 0118 908 AC cord connector base
CP102 960 0123 304 2P connector base
CP103 960 0128 901 3P connector base
CP104 960 0128 804 6P connector base
CP105 960 0123 304 2P connector base E3,EU,N
CP105 960 0123 304 2P connector base E2,EK,E2A,EUT,E1K
CP106 960 0123 207 3P connector base
CP501 963 0086 806 9P connector base (TUC-P)
CP502 963 0085 807 7P connector base (TUC-P) E3,EU,E2,EK,E2A,E1C,N
CP503,504 963 0086 903 5P connector base (TUC-P)
CP505 963 0088 008 10P connector base (TUC-P) E3,EU,E2,EK,E2A,E1C,N
CP555 963 0111 108 14P connector base (TUC-P) E3,EU,E2,EK,E2A,E1C,N
CP556 963 0087 805 11P connector base (TUC-P)
CP602,603 963 0087 601 8P connector base (TUC-P)
CP901 963 0048 909 3P connector base
CP931 960 0123 304 2P connector base E2,EK,E2A,EUT,E1K
CP931 960 0123 304 2P connector base E1C
CP992 963 0115 201 3P connector cord
! F101 963 0104 704 Fuse 2.5A E2,E2A,E1K
! F102 960 0188 705 Fuse 8A E3,EU,EUT,N
F102A,B 960 0005 804 Fuse clip
GND101-103 960 9006 600 Terminal
L101C,FL,FR,SL,SR 963 0049 005 Inductor 0.5uH
RLY101-104 960 0181 702 Relay (G5PA-28 24V)
RLY105 963 0071 303 Relay (RSB24S 24V)
RLY106 960 0181 605 Relay (G5PA-1-8 12V)
RLY107 960 0181 702 Relay (G5PA-28 24V)
TP101-105 960 0161 405 3P connector base
! - 963 0094 924 Power trans. (Mini) E3,EU,EUT
! - 963 0094 937 Power trans. (Mini) E2,EK,E2A
! - 963 0094 911 Power trans. (Mini) E1C,E1K
! - 963 0094 908 Power trans. (Mini) N
! - 963 0104 801 Fuse 3.15A E2,EK,E2A,E1C,E1K
- - Heat sink E3,EU
! - 960 0143 203 AC outlet E2,E2A
! - 960 0144 202 AC outlet E1K
- - Heat sink
- - Heat sink
- 963 0120 005 SW PUSH BLOCK
- 963 0119 809 4P speaker terminal
- 963 0119 906 8P speaker terminal
- 960 0194 508 1P pin jack
Ref. No. Part No. Part Name Remarks New
