Denon AVR-1604 Service Manual

40
40
AVR-1604/684 / AVC-1580
C446,447 963 9005 448 Ceramic 330pF/50V E2,EK,E2A
C446,447 963 9004 931 Ceramic 180pF/50V E1C,EUT,E1K
C448,449 963 9004 957 Ceramic 470pF/50V E3,EU
C448,449 963 9004 957 Ceramic 330pF/50V E1C,EUT,E1K
C450,451 963 9006 308 Electrolytic 10uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C453 963 9004 614 Ceramic chip 27pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C456 963 9004 672 Ceramic chip 680pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C461 963 9004 591 Ceramic chip 22pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C462 963 9004 656 Ceramic chip 470pF/50V E2,EK,E2A
C463 963 9004 782 Mylar film 0.056uF/100V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C464 963 9004 973 Ceramic 3pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C471VT 963 9006 379 Electrolytic 1uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C472VT 963 9004 753 Ceramic chip 0.047uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C481C,FL,FR 963 9004 575 Ceramic chip 100pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C481C,FL,FR,L,R 963 9004 575 Ceramic chip 100pF/50V N
C481SL,SR,SW 963 9004 575 Ceramic chip 100pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C481SL,SR,SW 963 9004 575 Ceramic chip 100pF/50V N
C490 963 9004 698 Ceramic chip 0.01uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C501SB 963 9006 382 Electrolytic 22uF/25V
C502SB 963 9006 308 Electrolytic 10uF/50V
C503SB 963 9003 165 Ceramic 220pF/500V
C504SB 963 9003 178 Ceramic 220pF/50V
C505SB 963 9003 181 Ceramic 33pF/500V
C506SB 963 9006 324 Electrolytic 100uF/10V
C507SB 963 9003 194 Mylar film 0.0022uF/100V
C551 963 9006 405 Electrolytic 2.2uF/50V
C551M 963 9006 353 Electrolytic 100uF/35V
C551S 963 9004 562 Ceramic 0.047uF/50V
C552-554 963 9006 366 Electrolytic 0.1uF/50V
C555,556 963 9004 546 Ceramic 0.01uF/16V
C557 963 9006 308 Electrolytic 10uF/50V
C558 963 9006 366 Electrolytic 0.1uF/50V
C621-623 963 9006 434 Electrolytic 47uF/16V
C624,625 963 9006 463 Electrolytic 470uF/6.3V
C626-628 963 9006 434 Electrolytic 47uF/16V
C629,630 963 9006 463 Electrolytic 470uF/6.3V
C631 963 9006 337 Electrolytic 100uF/16V
C632,633 963 9004 753 Ceramic chip 0.047uF/50V
C634,635 963 9006 379 Electrolytic 1uF/50V
C651-656 963 9006 476 Electrolytic 4.7uF/50V E3,EU
C657 963 9005 969 Electrolytic 4700uF/6.3V E3,EU
C658,659 963 9006 463 Electrolytic 470uF/6.3V E3,EU
C660-662 963 9006 324 Electrolytic 100uF/10V E3,EU
C671,672 963 9006 379 Electrolytic 1uF/50V E3,EU
C673 960 9003 108 Ceramic 0.022uF/25V E3,EU
C674 963 9006 324 Electrolytic 100uF/10V E3,EU
C681,682 963 9006 379 Electrolytic 1uF/50V E3,EU
C683 960 9003 108 Ceramic 0.022uF/25V E3,EU
C684 963 9006 324 Electrolytic 100uF/10V E3,EU
C691,692 963 9006 379 Electrolytic 1uF/50V E3,EU
C693 960 9003 108 Ceramic 0.022uF/25V E3,EU
C694 963 9006 324 Electrolytic 100uF/10V E3,EU
C701 963 9004 698 Ceramic chip 0.01uF/50V E3,EU
C702 963 9004 575 Ceramic chip 100pF/50V E3,EU
C703 960 9008 653 Mylar film 0.012uF/100V E3,EU
C704 963 9006 476 Electrolytic 4.7uF/50V E3,EU
C705 960 9008 653 Mylar film 0.012uF/100V E3,EU
C706 963 9006 434 Electrolytic 47uF/16V E3,EU
C707 963 0020 202 Ceramic 0.1uF/50V E3,EU
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
