Denon AVR-1604 Service Manual

41
41
AVR-1604/684 / AVC-1580
OTHER PARTS GROUP
BD701 960 0095 306 LINE FILTER BFS2550A0F1 E3,EU
CF401 960 0187 104 Ceramic filter SFE10.7MA8 E3,EU,E1C,EUT,E1K
CF401 960 0177 509 Ceramic filter SFE10.7MS3GH E2,EK,E2A
CF402 960 0187 104 Ceramic filter SFE10.7MA8 E3,EU
CF402 960 0177 509 Ceramic filter SFE10.7MS3GH E2,EK,E2A,E1C,EUT,E1K
CF403 960 0187 609 Ceramic resonator E3,EU,E2,EK,E2A,E1C,EUT,E1K
CN105 963 0089 405 2P connector cord E3,EU,E2,EK,E2A,EUT,E1K,N
CN401 963 0085 409 10P connector socket (TUC-P) E3,EU,E2,EK,E2A,E1C,EUT,E1K
CN402 963 0097 303 15P connector socket (TUC-P) E3,EU,E2,EK,E2A,E1C,EUT,E1K
CN402 963 0097 303 15P connector socket (TUC-P) N
CN552 963 0097 303 15P connector socket (TUC-P)
CN553 963 0085 409 10P connector socket (TUC-P)
CN554A 963 0115 104 12P WIRE
CN554B 963 0099 408 4P WIRE
CN555 963 0110 701 14P connector socket (TUC-P)
CN556 963 0086 709 11P connector socket (TUC-P)
CN603 963 0097 206 8P connector socket (TUC-P)
CN621 963 0085 603 5P connector socket (TUC-P)
CN651 963 0097 206 8P connector socket (TUC-P) E3,EU
CP551 963 0050 405 14P connector base
CP557 963 0115 007 13P WIRE
CP602B 960 0123 207 3P connector base
CP621 963 0086 903 5P connector base (TUC-P)
CP651 963 0087 601 8P connector base (TUC-P) E3,EU,N
! F101 960 0188 705 Fuse 8A E3,EU,EUT
F101A,B 960 0005 804 Fuse clip E3,EU,EUT,N
FE401 960 0187 706 Front end E3,EU,E2,EK,E2A,E1C,EUT,E1K
G401 963 0088 202 1P contact Ass'y E3,EU,E2,EK,E2A,E1C,EUT,E1K
L101SB 963 0049 005 Inductor 0.5uH
L401 963 0052 102 Inductor 1uH E3,EU,E2,EK,E2A,E1C,EUT,E1K
L402 960 0010 307 Inductor 10uH E3,EU,E2,EK,E2A,E1C,EUT,E1K
L403 963 0056 409 MW IF COIL RBW07VB-K5025 BLK E3,EU,E2,EK,E2A,E1C,EUT,E1K
T401 960 0186 600 MW IF COIL PCFMAF-270 E3,EU,E2,EK,E2A,E1C,EUT,E1K
T402 960 0007 349 FM DET TRANS E3,EU,E2,EK,E2A,E1C,EUT,E1K
T403 960 0007 352 FM DET TRANS E3,EU,E2,EK,E2A,E1C,EUT,E1K
T404,405 960 0071 207 MPX filter E2,EK,E2A
T406 960 0037 607 antibirdie filter E2,EK,E2A
TP106 960 0161 418 3P connector base
VR106 963 0105 208 Semi fixed resistor 1 kohm
VR401 960 0096 606 Semi fixed resistor 20kohm E3,EU,E2,EK,E2A,E1C,EUT,E1K
VR402 963 0056 205 Semi fixed resistor 50kohm E3,EU,E1C,EUT,E1K
VR402 960 0096 402 Semi fixed resistor 100kohm E2,EK,E2A
VR403 963 0052 005 Semi fixed resistor 200kohm E3,EU,E2,EK,E2A,E1C,EUT,E1K
X401 960 0187 405 Crystal 7.2 MHz E3,EU,E2,EK,E2A,E1C,EUT,E1K
X402 963 0043 302 Resonator CSB456F11 E3,EU,E2,EK,E2A,E1C,EUT,E1K
! - 960 0194 906 Fuse 8A N
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
