Denon AVR-1604 Service Manual

42
42
AVR-1604/684 / AVC-1580
- 960 0184 000 Screw bracket
- 963 0054 003 Shield tuner pack E3,EU,E2,EK,E2A,E1C,EUT,E1K
- 963 0099 000 EARTH "D"PLATE E3,EU,E2,EK,E2A,E1C,EUT,E1K
- 963 0052 403 3P antenna terminal E3,EU,E2,EK,E2A,E1C,EUT,E1K
- 960 0188 307 6P pin jack E3,EU,E2,EK,E2A,E1C,EUT,E1K
- 960 0181 304 3P S terminal
- 960 0181 401 4P S terminal
- 963 0071 002 Mini jack E3,EU
- 963 0106 906 6P pin jack E3,EU
- 963 0099 204 3P pin jack E3,EU
! - 963 0114 309 AC outlet(2P) E3,EU,EUT,N
- 960 0188 006 2P pin jack N
- 960 0188 307 6P pin jack N
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
