Denon AVR-1706 Service Manual

41
AVR-1706/686/1506/486
VEC303 00D 963 0095 208 SW,ENCODER EC16B24SA
! 00D 963 0232 100 STAND BY TRANS 120V/60HZ For AVR1706/686/1506/486E3,1706EUT
! 00D 963 0215 606 STAND BY TRANS 230V/50HZ For AVR1706E2
00D 963 0158 608 2P TER, SP
00D 963 0119 906 8P TER, SP
! 00D 960 0181 508 AC OUTLET(E3) For AVR1706/686/1506/486E3
! 00D 960 0143 203 AC OUTLET(E2) For AVR1706E2
! 00D 963 0236 407 AC OUTLET(EUT) For AVR1706EUT
-HEAT SINK
-HEAT SINK
00D 963 0018 007 SCREW, 3*8 B-TYPE ZNY/BH
nsp - COVER, CAPACITOR For AVR1706E2
nsp 00D 963 0247 001 LABEL, FUSE (F102) For AVR1706E2 *
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F101A
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F101B
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F102A
nsp 00D 960 0005 804 HOLDER,FUSE CLIP for F102B
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1706 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Composite video out	2
Component video (YPbPr/YCbCr) out	1
AC (power) in	Yes
Composite video in	4
Component video (YPbPr/YCbCr) in	3
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz
Optical drive included	No
Product color	Black
Audio decoders	DTS 96/24, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11.3 g
