Denon AVR-1706 Service Manual

51
AVR-1706/686/1506/486
INPUT P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC701 00D 963 0096 401 IC BD3811K1
IC701M 00D 963 0202 305 IC NJM2068M For AVR1706E3,E2,EUT,686E3
IC702 00D 963 0114 503 IC BD3812F
IC703 00D 960 0174 201 IC TC9273CNG-004 For AVR1706/686E3
IC705 00D 963 0202 305 IC NJM2068M For AVR1706/686/1506/486E3
IC761 00D 963 0202 305 IC NJM2068M
IC762 00D 963 0202 305 IC NJM2068M
IC763 00D 963 0202 305 IC NJM2068M
IC781 00D 963 0202 305 IC NJM2068M
IC782 00D 963 0202 305 IC NJM2068M
IC783 00D 963 0202 305 IC NJM2068M
IC784 00D 963 0202 305 IC NJM2068M
Q755 00D 963 0121 004 TR KRC104M For AVR1706/686/1506/486E3
Q758 00D 963 0120 704 TR KRA102S For AVR1706E2,EUT,1506/486E3
Q759 00D 960 0285 006 TR KRC104S For AVR1706E2,EUT,1506/486E3
Q760 00D 963 0121 004 TR KRC104M
Q771 00D 963 0121 004 TR KRC104M
Q772 00D 960 0097 207 TR KRA102M
Q773 00D 960 0196 807 FET 2SK117Y
Q774 00D 960 0196 807 FET 2SK117Y
D701 00D 963 0219 709 D, 1N4148W
D702 00D 963 0219 709 D, 1N4148W
D703 00D 963 0219 709 D, 1N4148W
D704 00D 963 0219 709 D, 1N4148W
D705 00D 963 0219 709 D, 1N4148W
D706 00D 963 0219 709 D, 1N4148W
D753 00D 963 0219 709 D, 1N4148W
D756 00D 963 0219 709 D, 1N4148W
D771 00D 963 0219 709 D, 1N4148W
D772 00D 963 0219 709 D, 1N4148W
ZD701 00D 960 0222 603 D,ZENER MTZJ7.5A
ZD701M 00D 960 0095 500 D,ZENER MTZJ5.1B For AVR1706E3,E2,EUT,686E3
ZD702 00D 960 0222 603 D,ZENER MTZJ7.5A
RESISTORS GROUP
R731 00D 963 9005 668 R,METAL FILM 220-J,1W
R732 00D 963 9005 668 R,METAL FILM 220-J,1W
R753 00D 960 9004 301 R,METAL FILM 47-J,1/4W For AVR1706/686/1506/486E3
R756 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R771 00D 963 9005 639 R,METAL FILM 100-J,1W
R772 00D 963 9005 639 R,METAL FILM 100-J,1W
R791 00D 963 9005 639 R,METAL FILM 100-J,1W
R792 00D 963 9005 639 R,METAL FILM 100-J,1W
CAPACITORS GROUP
C701CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V For AVR1706/686E3
C701L 00D 963 0223 601 C,CERAMIC 100PF-J/50V For AVR1706E2
C701M 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1706E3,E2,EUT,686E3
C701R 00D 963 0223 601 C,CERAMIC 100PF-J/50V For AVR1706E2
C702CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V For AVR1706/686E3
C702L 00D 963 0223 601 C,CERAMIC 100PF-J/50V For AVR1706E2
C702M 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1706E3,E2,EUT,686E3
C702R 00D 963 0223 601 C,CERAMIC 100PF-J/50V For AVR1706E2
C703CH 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V For AVR1706/686E3
C703L 00D 963 0223 601 C,CERAMIC 100PF-J/50V For AVR1706E2
C703M nsp 00D 963 0157 609 C,CERAMIC CHIP 150PF-J/50V For AVR1706E3,E2,EUT,686E3
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1706 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Composite video out	2
Component video (YPbPr/YCbCr) out	1
AC (power) in	Yes
Composite video in	4
Component video (YPbPr/YCbCr) in	3
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz
Optical drive included	No
Product color	Black
Audio decoders	DTS 96/24, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11.3 g
