Denon AVR-1706 Service Manual

48
AVR-1706/686/1506/486
CAPACITORS GROUP
C101SBL 00D 963 0234 506 C,ELECT 47UF-M/50V
C101SBR 00D 963 0234 506 C,ELECT 47UF-M/50V
C102SBL 00D 963 0234 205 C,ELECT 10UF-M/50V
C102SBR 00D 963 0234 205 C,ELECT 10UF-M/50V
C103SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C103SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C104SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C104SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V
C105SBL 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V
C105SBR 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V
C107SBL 00D 963 9003 097 C,FILM 0.1UF-K/250V
C107SBR 00D 963 9003 097 C,FILM 0.1UF-K/250V
C280 00D 963 0021 104 C,ELECT 6800UF-M/16V For AVR1706/686E3
C280A 00D 963 0224 804 C,ELECT 3300UF-M/25V For AVR1706/686E3
C281 00D 963 0224 804 C,ELECT 3300UF-M/25V For AVR1706/686E3
C401 00D 963 9005 804 C,ELECT 100UF-M/25V
C402 00D 963 9005 778 C,ELECT 10UF-M/50V
C403 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C404 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C405 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V For AVR1706/1506E3
C406 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V For AVR1706/1506E3
C407 00D 960 9008 653 C,FILM 0.012UF-J/100V For AVR1706/1506E3
C408 00D 960 9008 653 C,FILM 0.012UF-J/100V For AVR1706/1506E3
C409 00D 963 9005 859 C,ELECT 47UF-M/16V For AVR1706/1506/686E3
C410 00D 960 9010 146 C,ELECT 4.7UF-M/50V For AVR1706/1506E3
C411 00D 963 9006 104 C,ELECT 1UF-M/50V For AVR1706/1506E3
C481C nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C481FL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C481FR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C481SL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C481SR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C481SW nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C501C 00D 963 9006 544 C,ELECT 22UF-M/25V
C501FL 00D 963 9006 544 C,ELECT 22UF-M/25V
C501FR 00D 963 9006 544 C,ELECT 22UF-M/25V
C501M 00D 963 0234 205 C,ELECT 10UF-M/50V
C501SBL 00D 963 9006 544 C,ELECT 22UF-M/25V
C501SBR 00D 963 9006 544 C,ELECT 22UF-M/25V
C501SL 00D 963 9006 544 C,ELECT 22UF-M/25V
C501SR 00D 963 9006 544 C,ELECT 22UF-M/25V
C502C 00D 963 0234 205 C,ELECT 10UF-M/50V
C502FL 00D 963 0234 205 C,ELECT 10UF-M/50V
C502FR 00D 963 0234 205 C,ELECT 10UF-M/50V
C502SBL 00D 963 0234 205 C,ELECT 10UF-M/50V
C502SBR 00D 963 0234 205 C,ELECT 10UF-M/50V
C502SL 00D 963 0234 205 C,ELECT 10UF-M/50V
C502SR 00D 963 0234 205 C,ELECT 10UF-M/50V
C503C 00D 963 0216 207 C,CERAMIC 220PF 500V
C503FL 00D 963 0216 207 C,CERAMIC 220PF 500V
C503FR 00D 963 0216 207 C,CERAMIC 220PF 500V
C503SBL 00D 963 0216 207 C,CERAMIC 220PF 500V
C503SBR 00D 963 0216 207 C,CERAMIC 220PF 500V
C503SL 00D 963 0216 207 C,CERAMIC 220PF 500V
C503SR 00D 963 0216 207 C,CERAMIC 220PF 500V
C504C 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504FL 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504FR 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504SBL 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504SBR 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504SL 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C504SR 00D 963 0246 808 C,CERAMIC 220PF-K/50V *
C505C 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C505FL 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C505FR 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C505SBL 00D 963 0216 100 C,CERAMIC 33PF-J/500V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
