Denon AVR-1804 Service Manual

63
63
AVR-1804/884 / AVC-1880
D1000 963 0096 508 Diode 1N4148
D1001 963 0096 508 Diode 1N4148
D1002 963 0096 605 Diode 1N4148WS
D1003 963 0096 605 Diode 1N4148WS
D1004 963 0096 605 Diode 1N4148WS
D1005 963 0096 605 Diode 1N4148WS
D1006 963 0096 605 Diode 1N4148WS
D1007 963 0096 605 Diode 1N4148WS
D1009 963 0096 605 Diode 1N4148WS
D1010 963 0096 508 Diode 1N4148
D1011 963 0096 508 Diode 1N4148
D1012 963 0096 508 Diode 1N4148
D1013 963 0096 508 Diode 1N4148
D1014 963 0096 605 Diode 1N4148WS
ZD1000 960 0095 500 Zener diode MTZJ5.1B
RESISTORS GROUP
R104SB Metal oxide 5.6 kohm 1W
R105SB Metal oxide 5.6 kohm 1W
R106SB 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R107SB 963 9003 068 Metal film 4.7 ohm 1/4W (NB)
R108SB Metal oxide 0.22 ohm 1W
R109SB Metal oxide 0.22 ohm 1W
R110SB Metal oxide 0.22 ohm 1W
R1114 960 9003 807 Metal film 100 ohm 1/4W
R111SB Metal oxide 0.22 ohm 1W
R118SB Metal oxide 10 ohm 1W
R119SB Metal oxide 10 ohm 1W
R509SB 960 9005 902 Metal film 1.2 kohm 1/4W
R511SB 960 9004 301 Metal film 47 ohm 1/4W
VR106 Semi fixed resistor 1 kohm
CAPACITORS GROUP
C100 Electrolytic 22uF/25V
C1000 Electrolytic 22uF/25V
C1001 Electrolytic 22uF/25V
C1002 963 9005 312 Electrolytic 100uF/10V
C1003 963 9004 753 Ceramic chip 0.047uF/50V
C1004 963 9005 778 Electrolytic 10uF/50V
C1005 Electrolytic 22uF/25V
C1006 963 9004 753 Ceramic chip 0.047uF/50V
C1007 963 9005 778 Electrolytic 10uF/50V
C1008 963 9005 846 Electrolytic 2.2uF/50V
C1010 æޖس¡ØÃ? 560pF/50V
C1011 963 9004 520 Ceramic 100pF/50V
C1012 963 9004 520 Ceramic 100pF/50V
C1013 963 9005 778 Electrolytic 10uF/50V
C1014 Electrolytic 470uF/6.3V
C1015 963 9005 778 Electrolytic 10uF/50V
C1016 Electrolytic 470uF/6.3V
C1017 963 9005 778 Electrolytic 10uF/50V
C1018 Electrolytic 470uF/6.3V
C1019 963 9005 749 Electrolytic 1uF/50V
Ref. No. Part No. Part Name Remarks New

Denon AVR-1804 Specifications

General

Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Connector Type	RCA
Dimensions	434 x 168 x 391 mm
