Denon AVR-1804 Service Manual

65
65
AVR-1804/884 / AVC-1880
C232FR 963 9004 669 Ceramic chip 56pF/50V
C232SL 963 9004 630 Ceramic chip 39pF/50V
C232SR 963 9004 630 Ceramic chip 39pF/50V
C232SW 963 9004 669 Ceramic chip 56pF/50V
C235SW 963 9004 575 Ceramic chip 100pF/50V
C243 963 9004 753 Ceramic chip 0.047uF/50V
C244 963 9004 753 Ceramic chip 0.047uF/50V
C501SB 963 9005 820 Electrolytic 22uF/16V
C502SB 963 9005 778 Electrolytic 10uF/50V
C503SB 963 9003 165 Ceramic 220pF/500V
C504SB 963 9003 178 Ceramic 220pF/50V
C505SB 963 9003 181 Ceramic 33pF/500V
C506SB 963 9005 312 Electrolytic 100uF/10V
C507SB 963 9003 194 Mylar film 0.0022uF/100V
OTHER PARTS GROUP
CB1000 963 0053 800 BEADS INDUCTOR
CB1001 963 0053 800 BEADS INDUCTOR
CB1002 Inductor 33uH
CN1000 11P WIRE
CN1001 12P WIRE
CN1002 963 0085 409 10P connector socket (TUC-P)
CN1003 963 0085 700 6P connector socket (TUC-P)
CN105A 963 0059 105 2P connector cord E3,EU,EUT
CN503V 12P WIRE
CN507 963 0066 114 5P connector base E3,EU
CN555 963 0086 301 18P connector socket (TUC-P)
CN556 960 0239 900 13P connector socket (TUC-P)
CN602B 960 0123 207 3P connector base
CN704 963 0086 505 7P connector socket (TUC-P)
! F101 960 0188 705 Fuse 8A E3,EU,EUT
! F101 960 0194 906 Fuse 8A N
F101A 960 0005 804 Fuse clip E3,EU,EUT
F101B 960 0005 804 Fuse clip E3,EU,EUT
JACK201M 2P pin jack E3,EU
JK601 960 0188 200 4P pin jack
JK602 960 0188 404 3P pin jack
JK603 960 0188 404 3P pin jack
JK604 963 0057 000 1P pin jack
L1000 Y/C SEPARATE FILTER
L101SB 963 0049 005 Inductor 0.5uH
TP106 3P connector base
XTAL1000 CRYSTAL 14.31818MHz
! - AC outlet(2P) E3,EU,EUT
- SHIELD PLATE GND E3,EU
Ref. No. Part No. Part Name Remarks New

Denon AVR-1804 Specifications

General

Tuner	AM/FM
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
Connector Type	RCA
Dimensions	434 x 168 x 391 mm
