Denon AVR-2113 User Manual

44
n Skipping preset broadcast stations
(Preset Skip)
You can set in advance, the stations you do not want to be
displayed when tuning in, by groups or by stations.
The preset skip setting is useful when tuning in, because only your
favorite stations are displayed.
1
Press FM to switch the input source to “FM”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “Preset Skip”, then press ENTER.
The Preset Skip screen is displayed.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH01 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Name
Option
Preset Skip
GDisplay of this unitH
Preset Skip
Listening to FM broadcasts
4-1
GTo set the stations you want to skip by groupsH
q Use o p to select the group of broadcast
stations you want to skip.
•Each time o p is pressed, the setting is changed as
shown below.
1 – 8 9 – 16 25 – 3217 – 24
41 – 4849 – 56 33 – 40
w Press u to select “Set z – z to Skip”, then
press ENTER.
All broadcast stations in the group “z – z” you selected
are not displayed.
(z are the selected group numbers)
e Press BACK.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Skip
1 FM 87.50MHz On
Preset Group 1-8
2 FM 89.10MHz On
3 FM 98.10MHz On
4 FM 108.00MHz On
5 FM 90.10MHz On
6 FM 90.10MHz On
7 FM 90.10MHz On
8 FM 90.10MHz On
Set 1-8 to Skip
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Skip
1 FM 87.50MHz On
Preset Group 1-8
2 FM 89.10MHz On
3 FM 98.10MHz On
4 FM 108.00MHz On
5 FM 90.10MHz On
6 FM 90.10MHz On
7 FM 90.10MHz On
8 FM 90.10MHz On
Set 1-8 to Skip
GDisplay of this unitH
Set 1- 8to Skip
4-2
GTo set the stations you want to skip by stationsH
q Use o p to select the group of broadcast
stations you want to skip.
•Each time o p is pressed, the setting is changed as
shown below.
1 – 8 9 – 16 25 – 3217 – 24
41 – 4849 – 56 33 – 40
w Use ui to select the broadcast station you
want to skip.
e Use o p to select “Skip”.
The station you selected is not displayed.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Skip
1 FM 87.50MHz On
Preset Group 1-8
2 FM 89.10MHz On
3 FM 98.10MHz On
4 FM 108.00MHz On
5 FM 90.10MHz On
6 FM 90.10MHz On
7 FM 90.10MHz On
8 FM 90.10MHz On
Set 1-8 to Skip
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Skip
1 FM 87.50MHz Skip
Preset Group 1-8
2 FM 89.10MHz On
3 FM 98.10MHz On
4 FM 108.00MHz On
5 FM 90.10MHz On
6 FM 90.10MHz On
7 FM 90.10MHz On
8 FM 90.10MHz On
Set 1-8 to Skip
GDisplay of this unitH
1 87.50M:•Skp–
Basic version
Advanced version
Informations
Basic version
DVD

Denon AVR-2113 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	6
Audio (L/R) in	5
Composite video in	3
Component video (YPbPr/YCbCr) in	1
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	56
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Rotary
Multi-Zone quantity	2
Surround modes quantity	7
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	332 mm
Width	435 mm
Height	167 mm
Weight	9500 g
