45
Listening to FM broadcasts
Cancelling preset skip
1
While the Preset Skip screen is displayed, use o p
to select a group containing a broadcast station to
cancel the skip for.
2
Use ui to select a broadcast station to cancel the
skip for.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Preset Skip
1 FM 87.50MHz On
Preset Group 1-8
2 FM 89.10MHz On
3 FM 98.10MHz On
4 FM 108.00MHz On
5 FM 90.10MHz On
6 FM 90.10MHz On
7 FM 90.10MHz On
8 FM 90.10MHz On
Set 1-8 to Skip
GDisplay of this unitH
1 87.50M:•On –
3
Use o p to select “On”.
The skip is cancelled.
NOTE
You cannot cancel the skip for each group.
n RDS search
RDS (works only on the FM band) is a broadcasting service which
allows a station to send additional information along with the
regular radio program signal.
Use this function to automatically tune to FM stations that provide
the RDS service.
NOTE
Note that the RDS function only works when receiving RDS compatible
stations.
1
Press FM to switch the input source to “FM”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “RDS Search”, then press ENTER.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
Direct Tune
Option
RDS Search
PTY Search
TP Search
Radio Text
Preset Memory
Tune Mode
Auto Preset Memory
GDisplay of this unitH
RDS Search
4
Press ENTER.
The search for RDS stations begins automatically.
GTV ScreenH
TUNE+/-
STEREO
AUTO
CH / OPTION
FM
CH 1 FM 87.50MHz
Now Playing
Tune Preset Option
RDS Search
CH 1 FM 87.50MHz
- PS NAME -
Search
GDisplay of this unitH
RDS SEARCH
•If no RDS stations are found with the above operation, all the
reception bands are searched.
•When a broadcast station is found, that station’s name appears on
the display.
•If no RDS station is found when all the frequencies have been
searched, “NO RDS” is displayed.
If you press o p within 5 seconds after the broadcast station name is
shown on the display, you can search for a different station.
