Denon AVR-2113CI User Manual

80
Speaker connection
Connecting 6.1-channel speakers using one surround back
speaker
If using only one surround back speaker, connect to the “L” side of the SURROUND BACK terminal.
For speaker settings in this case, see “When 6.1ch speakers are installed” (vpage76).
To perform 6.1-channel playback using the surround back speaker, set “Assign Mode” to “Surround Back”
in steps 3 to 5 for “Set up “Amp Assign”” (vpage85).
Also use the “Speaker Config.” setting (vpage116) to set “Surr. Back” to “1spkr”.
Cables used for connections
Audio cable (sold separately)
Speaker
cable
Subwoofer
cable
NOTE
•For speaker cable connections, see page77.
•For speaker impedance , see page77.
FL FR
C
SL
SR
SW
SB
Basic version
Advanced version
Information
Advanced version
DVD
