131
Rear panel
See the page indicated in parentheses ( ).
q w e r t
u
yoQ2 iQ0Q1
q FM antenna terminal (ANTENNA) ········································· (20)
w Analog audio connectors (AUDIO) ······················ (14, 15, 16, 19)
e Subwoofer connector
(SUBWOOFER) ····································· (78, 79, 80, 81, 82, 83, 84)
r Speaker terminals
(SPEAKERS) ········································· (78, 79, 80, 81, 82, 83, 84)
t Component video connectors
(COMPONENT VIDEO) ·········································· (14, 15, 16, 17)
y Power cord ··············································································· (23)
u HDMI connectors ································································· (9, 10)
i Digital audio connectors
(DIGITAL AUDIO) ······································· (13, 14, 15, 16, 17, 19)
o Network connector (NETWORK) ··········································· (22)
Q0 REMOTE CONTROL jacks ······················································· (21)
Q1 Video connectors (VIDEO) ·········································· (13, 14, 15)
Q2 RC-232C connector ·································································· (21)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
