Denon AVR-2308CI - Page 4

Partner: Denon
Model: AVR-23/28/38/43/5805CI +
888 + 988
Device Type: AV Surround Receiver
HD_Tuner_Next/Previous_Preset D Pulse to step through the tuner presets for HD AM/FM.
Key_XM_* D
Pulse for direct key tuner entry. Note: At least one tuner (Analog, XM, DAB or HD)
has to be selected in at least 1 zone for direct tuning to work. There are 4
separate keyboard entry mechanisms (Analog, HD, XM and DAB). Band must be
selected first to enable keyboard function.
XM_Tuner_Frequency_Up/Down D Press and hold to adjust the tuner channel for XM.
XM _Preset Memory D Press to set XM tuning to a preset.
XM_Tuner_Preset_* D Pulse to select the desired preset for XM.
XM_Tuner_Next/Previous_Preset D Pulse to step through the tuner presets for XM.
Key_DAB_* D
Pulse for direct key tuner entry. Note: At least one tuner (Analog, XM, DAB or HD)
has to be selected in at least 1 zone for direct tuning to work. There are 4
separate keyboard entry mechanisms (Analog, HD, XM and DAB). Band must be
selected first to enable keyboard function.
DAB_Tuner_Frequency_Up/Down D Press and hold to adjust the tuner channel for DAB.
DAB _Preset Memory D Press to set DAB tuning to a preset.
DAB_Tuner_Preset_* D Pulse to select the desired preset for DAB.
DAB_Tuner_Next/Previous_Preset D Pulse to step through the tuner presets for DAB.
Initialize D Pulse to initialize.
From_Device$ S Serial signal to be routed from a 2-way serial com port.
FEEDBACK:
Power_On/Off_Fb D High to indicate the current power state of the unit.
Main_Zone_On/Off_Fb D High to indicate the current main zone status.
Main_Input_*_Fb D High to indicate the current main zone source.
Main_Volume_Bar
A
Analog value indicating the current main zone volume level. To be displayed using
a bar graph on a touch panel.
Main_Volume_Text$ S Serial signal indicating the current main zone volume level.
