Page #84 background imageLoading...
Page #84 background image
81
ENGLISH
Basic versionSimple version InformationAdvanced version
Remote control operation
buttons
Move the cursor
(Up/Down/Left/Right)
Confirm the setting Return to previous menu
Manual Setup
Setting items Setting details
Distance
(Continued)
• The speakers that can be selected differ depending on the “Amp Assign”
(vpage79) and “Speaker Config.” (vpage79) settings.
Default settings :
Front L / Front R / Center / Subwoofer / F.Height L / F.Height R / F.Wide L /
F.Wide R : 12.0 ft (3.6 m)
Surround L / Surround R / S.Back L / S.Back R : 10.0 ft (3.0 m)
Set the difference in the distance between the speakers to less than 20
ft (6.0 m).
NOTE
Speakers set to “None” in “Speaker Config.” (vpage79) are not displayed.
Default : The “Distance” settings are returned to the default settings.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Default” and press ENTER, the “Default Setting?”
prompt is displayed. Select either “Yes” or “No”, and press
ENTER.
Channel Level
Set the volume of the test
tone to be the same when it
is output from each speaker.
Test Tone Start : Output test tone.
Front L / F.Height L / Center / F.Height R / Front R / F.Wide R /
Surround R / S.Back R
z
/ S.Back L
z
/ Surround L / F.Wide L /
Subwoofer : Select the speaker.
z When the “Speaker Config.” – “S.Back” setting (vpage80) is set to
“1spkr”, “S.Back” is displayed.
–12.0dB – +12.0dB (0.0dB) : Adjust the volume.
• When
o is pressed while the subwoofer volume is set to “–12 dB”, the
“Subwoofer” setting switches to “OFF”.
• When “Channel Level” is adjusted, the adjusted values are set for all the
surround modes. To adjust the channel level separately for the different
surround modes, use the operation see page 55.
NOTE
Speakers set to “None” in the “Speaker Config.” (vpage79) settings
are not displayed.
When a headphones jack is inserted in the PHONES jack of this unit, the
“Channel Level” is not displayed.
Default : The “Channel Level” settings are returned to the default settings.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Default” and press ENTER, the “Default Setting?”
prompt is displayed. Select either “Yes” or “No”, and press
ENTER.
Setting items Setting details
Crossover Frequency
Set the maximum frequency
of the bass signal output
from each channel to
the subwoofer. Set the
Crossover Frequency to
suit the bass reproduction
capability of the speaker
being used.
Crossover : Set the crossover frequency.
40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz
Advanced : Specify crossover frequency for each speaker.
Front / Center / Surround / S.Back / F.Height / F.Wide : Select the
speaker.
40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz : Set the crossover frequency.
“Crossover Frequency” can be set when the “Bass Setting” –
“Subwoofer Mode” (vpage80) setting is “LFE+Main”, or when you
have a speaker that is set to “Small”.
Always set the crossover frequency to “80Hz”. When using small
speakers, however, we recommend setting the crossover frequency to
a higher frequency.
For speakers set to “Small”, sound below the crossover frequency
is cut from the sound output. The cut bass sound is output from the
subwoofer or front speakers.
The speakers that can be set when “Advanced” is selected differ
depending on to the “Subwoofer Mode” setting (vpage80).
When “LFE” is selected, speakers set to “Small” at “Speaker Config.”
can be set. If the speakers are set to “Large”, “Full Band” is displayed
and the setting cannot be made.
If set to “LFE+Main”, this setting can be made regardless of the
speaker size.
Front Speaker Setup
Set the front speakers to
use for every surround
mode.
NOTE
This can be set when “Amp
Assign” is set to “Front B”
(vpage79).
2CH DIRECT/STEREO : The front speakers used in the direct, stereo and
pure direct play modes (2 channel) are set in advance.
A : Front speaker A is used.
B : Front speaker B is used.
A+B : Both front speakers A and B are used.
MULTI CH : The front speakers used in modes other than the direct,
stereo and pure direct play modes (2 channel) are set in advance.
A : Front speaker A is used.
B : Front speaker B is used.
A+B : Both front speakers A and B are used.
