Denon AVR-3311 User Manual

24
ENGLISH
Playback (Basic operation)
n Playing a Blu-ray Disc player/DVD player
(vpage25)
n Playing a CD player (vpage25)
n Playing an iPod
®
(vpage25)
n Tuning in radio stations (vpage28)
n Playing a network audio (vpage32)
n Playing a USB memory device (vpage43)
Selecting a listening mode (Surround mode)
(vpage45)
n Selecting the input source (vpage24)
n Adjusting the master volume (vpage24)
n Turning off the sound temporarily (vpage25)
Playback (Advanced operation) (vpage54)
Important information
Before starting playback, make the connections between the different
components and the settings on the receiver.
NOTE
Also refer to the operating instructions of the connected components
when playing them.
Selecting the input source
3UHVV WKH LQSXW VRXUFH VHOHFW EXWWRQ

NET/USB iPod DVD BD TUNER
DOCK SAT TU SAT/CBL GAME
V.AUX PHONO CD DVR TV WR EH
SOD\HGEDFN
The desired input source can be selected
directly.
• When iPod PLAY is pressed, the input source of this unit is
switched to “DOCK” or “NET/USB” and the connected iPod is
automatically played (vpage28 “iPod play function”).
You can also use the following operation to select an input
source.
n Using the “Source Select” menu
q Press SOURCE SELECT.
Display the “Source Select” menu.
6RXUFH6HOHFW)OLFNU
5HFHQW6RXUFH
(QWHU
6HOHFW
(17(5
The currently selected input
source is highlighted.
q
w
e
q Input Source
The name of the highlighted input source is displayed.
w Recently used sources
The recently used input sources (up to five) are displayed.
e Icons for the input sources in the different categories are
displayed.
w Use uio p to select the input source,
then press
ENTER.
The input source is set and the source
selection menu is turned off.
• When using with an iPod connected directly to the USB port of this
unit, select “
(USB/iPod)” for the input source.
• Input sources that are not going to be used can be set ahead of time.
Make this setting at “Source Delete” (vpage87).
• To turn off the source selection menu without selecting an input
source, press
SOURCE SELECT again.
n Using the knob on the main unit
Turn SOURCE SELECT.
• If “Rec Select” or “Tuning Preset”
mode is selected for the input
source, press
SOURCE before
turning
SOURCE SELECT.
• Turning SOURCE SELECT switches
the input source, as shown below.
BD DVD TV SAT/CBL GAMEDVR
V.AUX
PHONO HD Radio SIRIUS NET/USB DOCKCD
Adjusting the master volume
8VHVOL dfWRDGMXVWWKHYROXPH
n When the “Volume Display” setting
(vpage87) is “Relative”
GAdjustable rangeH
– – – –80.5dB – 18.0dB
n When the “Volume Display” setting (vpage87) is
“Absolute”
GAdjustable rangeH
0.0 – 99.0
• The variable range differs according to the input signal and channel
level setting.
You can also operate via the main unit.
In this case, perform the following
operations.
Turn
MASTER VOLUME to adjust the
volume.

Denon AVR-3311 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Optical drive included	No
Display	LED
Equalizer	Yes
HDMI version	1.4a
Product color	Silver
Audio decoders	DTS 96/24, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD
Volume control	Rotary
Multi-Zone quantity	4
Apple docking compatibility	iPod Classic 4, iPod Classic 5, iPod Mini 1, iPod Mini 2, iPod Nano 1, iPod Nano 2
Supported video modes	1080p
HDMI in	6
Audio (L/R) in	9
Composite video in	5
USB ports quantity	1
S-Video inputs quantity	2
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
AM band range	522 - 1611 kHz
FM band range	57.5 - 108 MHz
Composite video out	3
Headphone connectivity	3.5 mm/6.35 mm
Digital audio coaxial out	0
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	381 mm
Width	434 mm
Height	171 mm
Weight	12200 g
