Denon AVR-3803 Control Protocol

- 5 -
COMMAND PARAMETER function example
CV SB UP ---SURROUND BACKch (SBch 1SP) CVSB UP<CR>
SB DOWN CVSB DOWN<CR>
SB ** **:38 to 62 by ASCII , 50=0dB CVSB 50<CR>
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO Select INPUT source SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS/SAT ---Select DBS function at AVR-3803 SIDBS/SAT<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 ---Invalid at AVR-3803 SIVCR-3<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE1 ---Select CDR/TAPE function at AVR-3803 SICDR/TAPE1<CR>
MD/TAPE2 ---Invalid at AVR-3803 SIMD/TAPE2<CR>
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
Z1 PHONO MULTI ZONE-1 mode set , and select source Z1PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. Z1CDR/TAPE1<CR>
SOURCE MULTI ZONE-1 mode cancel Z1SOURCE<CR>
UP MULTI ZONE-1 VOLUME UP/DOWN , direct change to ***dB Z1UP<CR>
DOWN Z1DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 00=---(MIN) Z180<CR>
ON MULTI ZONE-1 ON/OFF change Z1ON<CR>
OFF Z1OFF<CR>
---Set ZONE-2 functions at AVR-3803

Denon AVR-3803 Specifications

General

Channels	7.1
Dolby Digital	Yes
DTS	Yes
Component Video Inputs	3
S-Video Inputs	7
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
Analog Audio Inputs	9
Type	AV Receiver
THD	0.05%
Input Sensitivity	200 mV
Signal to Noise Ratio	100 dB
Frequency Response	10 Hz - 100 kHz
Digital Inputs	5 (3 Optical, 2 Coaxial)
Weight	33.1 lbs
Amplifier Channels	7
Signal-to-Noise Ratio	100 dB
Surround Sound Modes	Dolby Digital, DTS, Dolby Pro Logic II
Power Output	110W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Video Inputs	S-Video, Component
Input Sensitivity/Impedance	200 mV / 47 kOhm
Video Inputs/Outputs	S-Video, Component
Dimensions (W x H x D)	17.1 x 6.6 x 16.9 inches
