Denon AVR-3803 Control Protocol

- 6 -
COMMAND PARAMETER function example
Z2 PHONO MULTI ZONE-2 mode set , and select source Z2PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z2MD/TAPE2<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
UP MULTI ZONE-2 VOLUME UP/DOWN , direct change to ***dB Z2UP<CR>
DOWN Z2DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB Z280<CR>
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
---Invalid at AVR-3803
SR PHONO REC SELECT mode set , and select source SRPHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. SRCDR/TAPE1<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>
SV DVD VIDEO SELECT mode set , and select source SVDVD<CR>
VDP SVVDP<CR>
TV SVTV<CR>
DBS/SAT SVDBS/SAT<CR>
VCR-1 SVVCR-1<CR>
VCR-2 SVVCR-2<CR>
VCR-3 ---Invalid at AVR-3803 SVVCR-3<CR>
V.AUX SVV.AUX<CR>
SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>
SD AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR>
PCM set DIGITAL INPUT force PCM mode SDPCM<CR>
DTS set DIGITAL INPUT force DTS mode SDDTS<CR>
RF ---Invalid at AVR-3803 SDRF<CR>
ANALOG set force ANALOG INPUT mode SDANALOG<CR>
EXT.IN-1 set EXT.IN-1 mode ---Set EXT.IN mode at AVR-3803 SDEXT.IN-1<CR>
EXT.IN-2 set EXT.IN-2 mode ---Invalid at AVR-3803 SDEXT.IN-2<CR>

Denon AVR-3803 Specifications

General

Channels	7.1
Dolby Digital	Yes
DTS	Yes
Component Video Inputs	3
S-Video Inputs	7
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
Analog Audio Inputs	9
Type	AV Receiver
THD	0.05%
Input Sensitivity	200 mV
Signal to Noise Ratio	100 dB
Frequency Response	10 Hz - 100 kHz
Digital Inputs	5 (3 Optical, 2 Coaxial)
Weight	33.1 lbs
Amplifier Channels	7
Signal-to-Noise Ratio	100 dB
Surround Sound Modes	Dolby Digital, DTS, Dolby Pro Logic II
Power Output	110W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Video Inputs	S-Video, Component
Input Sensitivity/Impedance	200 mV / 47 kOhm
Video Inputs/Outputs	S-Video, Component
Dimensions (W x H x D)	17.1 x 6.6 x 16.9 inches
