Thank you very much for purchasing the DENON component
DRS-810.
The DENON DRS-810 is a top-of-the-line stereo cassette tape
deck, capable of outstanding performance in combination
with high-grade hi-fi systems.
DENON proudly presents this advanced tape deck to audio-
philes and music lovers as a further proof of DENON’s non-
compromising pursuit of the ultimate in sound quality. The
high quality performance and easy operation are certain to
provide you with many hours of outstanding listening
pleasure.
— TABLE OF CONTENTS —
FEA TURES 3 s2esdiine cutee, Stes bee pore tie a LS eee te 3
CONNECTIONS 25 heeds diese snctin penne Eee ee ee eee 3
NAMES AND FUNCTIONS OF PARTS............----0005 4A~5
CASSETTE APES s2c.i5 3 tieetews mas cup eeiie adeno beatae eee 5
AUTO TAPE SELECT FEATURE..............0.0.-0 0c eee 6
PLAYBACK 23 24. insect. lee thd ous sha wk edaedaharscie wee dees 6
RECORDING © 25. ou ccee ic oecee sce we cwsoddee seule ag ecewen 7
MUSIC SEARCH SYSTEM. ......... 0... cece cece ence ee eenes 8
PROPER RECORDING LEVEL ...............0ccc cee ee eens 8
RECORDING BIAS ADJUSTMENT................2..0.0000e 8
REC/REC MUTE AND PAUSE BUTTON..................... 8
TAPE COUNTER AND MEMORY STOP..................005 9
TAPE MONITOR BUTTON.............. 0.0.0.0 c cece ee eee 10
DOLBY B & C NOISE REDUCTION SYSTEM............. 10
DOLBY HX-PRO HEADROOM EXTENSION SYSTEM......... 10
TIMER RECORDING/PLAY BACK ................2.220.005. 11
TROUBLESHOOTING ........ 0. cece cece cece eee eens 12
SPECIFICATIONS en5.0l.05 torkanears th eke thee de ied bone 12
CONNECTION
e Leave your entire system (including this cassette deck)
turned off until all connections between the deck and other
components have been completed.
Receiver or amplifier
@ Connecting the Deck to an Amplifier
e Before connecting the deck to your amplifier, please
review your amplifier’s instruction manual.
«Use the white plugs for the left channel and red plugs
for the right channel.
M@ Tape Dubbing
® Many stereo amplifiers and receivers have tape dubbing
circuitry so that tape duplication can be performed
between two or more tape decks. Review your amplifier’s
instruction manual for a full explanation of this mode
of operation.
ENGLISH
Please check to make sure the following items are
included with the main unit in the carton:
(1) Operating Instructions ....................0. 1
(2) Connection Cords.............. 2. cee ee eee 2
FEATURES
@ Computer controlled silent mechanism
™@ Closed-loop dual-capstan tape transport.
@ Non-Slip Reel Drive for Stabilizing Tape Tension
H Dual Power Supply
@ Dolby HX-Pro Headroom Extension System
H Dolby B & C Noise Reduction Systems
M@ Manual Bias Adjustment Control
BW Computing Linear Tape Counter with 4-Digit Readout and
Memory Stop
W Cassette Stabilizer
@ Remaining Tape Counter
@ Music Search System
W REC Return System
MFL Peak Level Meters
@ Auto Tape Selector
™ Optional remote control system
Cassette deck
a7
J]
LI
50/60Hz
Connecting Headphones
To listen through headphones, plug your headphohesimto
the PHONES jack.
HB installation Precautions
lf the deck is placed near an amplifier or tuner, to ise
(induced hum) or beat interference may result, espeially
during FM or AM reception. If this occurs, place thedeck
further away from other components or reorient its
position.
