Denon AVR-3805 Service Manual

62
62
AVR-3805 / AVC-3890
C311,312 257 0509 929 CK73B1H102KT
C313,314 255 1264 982 CQ93M1H472JT(B)
C315,316 257 0509 929 CK73B1H102KT
C401,402 254 4313 934 CE04W1H470MT(ASF)
C403-406 254 4586 936 CE04W2A4R7MT(RE3)
C407,408 255 1279 919 CQ93M1H473JT(B)
C409,410 255 1264 982 CQ93M1H472JT(B)
C411,412 257 0509 929 CK73B1H102KT
C502 254 4649 909 CE04W1H010MT(PWX) *
C503-505 256 1064 907 CF93A2E334KT(B)L=16
C506 254 4587 715 CE04W2A101MC(RE3)
C507,508 254 6231 700 CE68W==153MC(DL)L=60
C516 254 4368 934 CE04W1E101MT(ASF)
C517 254 4313 963 CE04W1H010MT(ASF)
C522 254 4403 721 CE04W1E222MC (SMG)
C523 255 4256 997 CQ93P2A153JT(NH2)
C524 255 1279 951 CQ93M1H104JT(B)
C599 254 4583 900 CE04W1H010MT(ROB) *
C601-604 257 0512 903 CK73F1E104ZT
C615 254 4583 900 CE04W1H010MT(ROB) *
C616-635 254 4573 994 CE04W1H220MT(RE3)
C636 257 0512 903 CK73F1E104ZT
C637 254 4583 900 CE04W1H010MT(ROB) *
OTHER PARTS GROUP
CW47 203 6606 007 4P KR-DA CON.CORD *
CW62 205 0942 019 6P CON.SOCKET(TUC-P
CW153 205 0885 040 15P CON.SOCKET TUC-P
CX33 205 0825 000 3P AC CON.BASE
CX35,36 205 0696 035 JL CONNECTOR(BT-E)
CX44 205 0884 083 4P CON.BASE(TUC-P)
CX63-69 205 0943 018 6P CON.BASE(TUC-P)
CX82 205 0884 096 8P CON BASE(TUC-P)
CX118 205 1091 024 11P CON BASE TWG-P
CX134 205 1091 037 13P CON BASE TWG-P
JK501 205 1250 001 8P SP TERMINAL(V0)
JK502 205 1252 009 4P SP TERMINAL(V0)
JK503 205 1251 000 6P SP TERMINAL(V0)
JK801 204 8540 009 4P PIN JACK
JK802 204 8655 004 6P PIN JACK (S2GND)
L101,102 235 0068 004 INDUCTOR(1MH)
L201 235 0068 004 INDUCTOR(1MH)
L301,302 235 0068 004 INDUCTOR(1MH)
L401,402 235 0068 004 INDUCTOR(1MH)
RL101 214 0217 007 RELAY(DS24D2)
RL201 214 0217 007 RELAY(DS24D2)
RL301,302 214 0217 007 RELAY(DS24D2)
RL401 214 0217 007 RELAY(DS24D2)
RL501 214 0223 004 RELAY(EC2-24N35)
! T501 233 6434 005 MINI TRANS(383E2)
TP101 205 0190 065 6P NH CONNECTOR BASE
TP301 205 0190 081 8P NH CONNECTOR BASE
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
