Denon AVR-3805 Service Manual

99
99
AVR-3805 / AVC-3890
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty New
1 1U-3469N POWER UNIT ASS'Y for EU,EC 1 *
1 1U-3469Q POWER UNIT ASS'Y for E2,E2A 1 *
1 1U-3469U POWER UNIT ASS'Y for E1C,E1K 1 *
1 1U-3469S POWER UNIT ASS'Y for EUT 1 *
1 1U-3469R POWER UNIT ASS'Y for JP 1 *
1-1 - POWER UNIT
1-6 - PRE OUT UNIT
2 1U-3601 CONNECT/VIDEO UNIT ASS'Y for EU,EC 1 *
2 1U-3601B CONNECT/VIDEO UNIT ASS'Y for E2,E2A 1 *
2 1U-3601F CONNECT/VIDEO UNIT ASS'Y for E1C,E1K 1 *
2 1U-3601E CONNECT/VIDEO UNIT ASS'Y for EUT 1 *
2 1U-3601D CONNECT/VIDEO UNIT ASS'Y for JP 1 *
2-1 - CONNECT UNIT
2-2 - FUNC.SEL UNIT
2-3 - S-VIDEO UNIT
2-4 - C-VIDEO UNIT
2-5 - VOL UNIT
2-6 - REMOTE I/O UNIT
2-8 - P.SW UNIT
2-9 - LED UNIT
2-10 - 232C UNIT
2-11 - H/P UNIT
3 1U-3596 CONTROL UNIT ASS'Y for EU,EC 1 *
3 1U-3596B CONTROL UNIT ASS'Y for E2,E2A 1 *
3 1U-3596F CONTROL UNIT ASS'Y for E1C,E1K 1 *
3 1U-3596E CONTROL UNIT ASS'Y for EUT 1 *
3 1U-3596D CONTROL UNIT ASS'Y for JP 1 *
3-1 - CONTROL UNIT
3-2 - TACT 38 UNIT
3-5 - COMP.3IN UNIT for EU,EC,E2,E2A,E1C,EUT,E1K
3-7 - VCONNECT UNIT
3 1U-3611 D VIDEO UNIT ASS'Y for JP 1 *
3-5 - D VIDEO UNIT for JP
4 1U-3472N AMP CONNECT UNIT ASS'Y for EU,EC 1 *
4 1U-3472Q AMP CONNECT UNIT ASS'Y for E2,E2A 1 *
4 1U-3472U AMP CONNECT UNIT ASS'Y for E1C,E1K 1 *
4 1U-3472S AMP CONNECT UNIT ASS'Y for EUT 1 *
4 1U-3472R AMP CONNECT UNIT ASS'Y for JP 1 *
4-1 - REGULATOR UNIT
4-2 - AMP CONNECT UNIT
4-3 - AC IN UNIT
4-4 - EXT.IN CONN.UNIT
4-5 - TU CONNECT UNIT
4-6 - AUDIO CONN. UNIT
5 1U-3595 AUDIO/DIGITAL UNIT ASS'Y for EU,EC 1 *
5 1U-3595B AUDIO/DIGITAL UNIT ASS'Y for E2,E2A 1 *
5 1U-3595F AUDIO/DIGITAL UNIT ASS'Y for E1C,E1K 1 *
5 1U-3595E AUDIO/DIGITAL UNIT ASS'Y for EUT 1 *
5 1U-3595D AUDIO/DIGITAL UNIT ASS'Y for JP 1 *
5-1 - DIGITAL UNIT
5-2 - AUDIO IN UNIT
5-3 - EXT.IN VR UNIT
5-4 - V.AUX UNIT
5-5 - MIC AMP UNIT
6 1U-3551 DSP ADI EX UNIT ASS'Y 1 *
Note : The symbols in the column “Remarks” indicate the following destinations.
EU : U.S.A. model E1C : China model
EC : Canada model EUT : Taiwan R.O.C. model
E2 : Europe model E1K : Korea model
E2A : Asia model JP : Japan model

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
