AVR-3805 / AVC-3890
7 1U-3602 VIDEO CONV. UNIT ASS'Y for EU,EC 1 *
7 1U-3602B VIDEO CONV. UNIT ASS'Y for E2,E2A 1 *
7 1U-3602F VIDEO CONV. UNIT ASS'Y for E1C,E1K 1 *
7 1U-3602E VIDEO CONV. UNIT ASS'Y for EUT 1 *
7 1U-3602D VIDEO CONV. UNIT ASS'Y for JP 1 *
7-1 - CONVERT UNIT
7-2 - FLD UNIT
7-3 - FLD SUPPLY UNIT
8 411 2031 251 MAIN CHASSIS 1 *
9 412 4692 109 TRANS BRACKET 1
10 412 4210 002 BRACKET 2
11 412 4716 014 SUPPORT BRACKET 1
12 104 0334 007 FOOT 4
13 461 0385 001 RUBBER PAD 4
14 412 3548 005 P.W.B CATCHER 3
16 412 5025 005 SIDE BRACKET for E2,E2A,E1C,E1K 1
17 412 2814 028 CARD SPACER(L=10) 14
18 461 0573 062 RUBBER SHEET 2
19 144 2872 002 FRONT PANEL for black model 1 *
19 144 2872 015 FRONT PANEL for silver model 1 *
19 144 2872 028 FRONT PANEL for E2A,E1C,EUT,E1K 1 *
19 144 2872 031 FRONT PANEL for JP 1 *
20 131 0158 007 DENON BADGE for black model 1
20 131 0158 023 DENON BADGE for silver model 1
20 131 0158 010 DENON BADGE for gold model 1
21 412 2814 031 CARD SPACER (L=4) 1
22 412 2814 099 CARD SPACER (L=2.5) 1
23 412 2741 052 P.W.B HOLDER(H=22) 1
24 412 2404 056 PWB HOLDER (WLS-18) 1
25 414 0996 009 SHIELD PLATE (D) 1 *
26 409 0052 019 HOLDER (A) 1
27 412 2404 043 PWB HOLDER (WLS-13) 2
28 461 0714 009 CUSHION(B) 1
30 105 1451 209 BACK PANEL for EU,EC 1 *
30 105 1451 212 BACK PANEL for E2,E2A 1 *
30 105 1451 254 BACK PANEL for E1K 1 *
30 105 1451 238 BACK PANEL for E1C 1 *
30 105 1451 241 BACK PANEL for EUT 1 *
30 105 1451 267 BACK PANEL for JP 1 *
31 449 0070 002 LOCKING CARD SPACER 1
32 414 0995 000 SHIELD PLATE (A) 1 *
33 205 1116 006 TERMINAL ASS 1
34 216 0117 006 AM FM TUNER(E3) for EU,EC 1
34 216 0118 005 AM FM TUNER(E2) for E2,E2A,E1C,E1K 1
34 216 0119 004 AM FM TUNER(E1) for EUT 1
! 36 203 3996 008 AC INLET (2P) for EU,EC,E2,E2A,E1C,EUT,E1K 1
! 36 203 3983 008 AC INLET for JP 1
! 38 203 3981 000 AC OUTLET (E2) for E2,E2A 1
42 146 2349 007 INNER PANEL ASS'Y for EU black model,EC 1 *
42 146 2349 010 INNER PANEL ASS'Y for EU silver model 1 *
42 146 2349 023 INNER PANEL ASS'Y for E2 black model 1 *
42 146 2349 036 INNER PANEL ASS'Y for E2 silver model 1 *
42 146 2349 049 INNER PANEL ASS'Y for gold model 1 *
44 143 1189 007 POWER LENS 1 *
45 417 0638 104 RADIATOR 1
46 417 0639 006 CU PLATE 1
47 - MICA SHEET 14
48 274 0196 010 MN15N LF551 TR101,102,201,301,302,401,402 7
49 272 0157 011 MP15P LF551 TR103,104,203,303,304,403,404 7
50 412 4127 001 PWB BRACKET (B) 2
51 412 4995 000 RADIATOR BRACKET (F) 1
Ref. No. Part No. Part Name Remarks Q'ty New
To Next Page
