Denon AVR-3805 Service Manual

70
70
AVR-3805 / AVC-3890
AUDIO/DIGITAL UNIT
Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101 262 3347 009 TC94A46FG *
IC102 263 0896 909 NJM2068MD-TE1
IC103-106 263 1098 900 LM833MX
IC107,108 263 0896 909 NJM2068MD-TE1
IC201-203 263 0615 902 BA15218F-DXE2
IC204 269 0221 006 GP1FM313RZ *
IC207 263 1098 900 LM833MX
IC209 263 0615 902 BA15218F-DXE2
IC301 262 2919 001 TC9274N-017
IC302,303 263 0896 909 NJM2068MD-TE1
IC304 263 1098 900 LM833MX
IC371 262 3168 903 TC94A32F
IC372 263 1207 908 AD8512AR REEL *
IC373 262 3168 903 TC94A32F
IC374 263 1207 908 AD8512AR REEL *
IC376 262 3168 903 TC94A32F
IC377 263 1207 908 AD8512AR REEL *
IC378 262 3168 903 TC94A32F
IC379 263 1207 908 AD8512AR REEL *
IC381 262 2540 904 TC9459F-EL
IC382 263 0615 902 BA15218F-DXE2
IC508 263 0934 900 BA4510F-E2
IC515 263 0934 900 BA4510F-E2
IC517 263 0934 900 BA4510F-E2
IC519 262 3069 905 PCM1804
IC523-526 262 3332 904 PCM1791ADBR
IC527 263 1098 900 LM833MX
IC529 263 1098 900 LM833MX
IC531 263 1098 900 LM833MX
IC533 263 1098 900 LM833MX
IC535 263 1098 900 LM833MX
IC536 263 1079 903 BA033FP
IC730 263 0896 909 NJM2068MD-TE1
IC801 262 3106 907 SN65LVDS32PW
IC802 262 3125 904 SN65LVDS179DGK-EL2
IC803,804 262 3077 900 TC74VHCU04FT
IC805 262 2557 900 SN74LV14APW-EL2
IC806,807 262 2944 908 SN74HC151APW-EL2
IC808-811 262 3065 006 TORX141
IC812,813 262 3064 007 TOTX141
IC814-816 262 3066 115 LC89057W-VF4D-E *
IC817 262 3062 902 FCX0-03(24.576MHZ)
IC818 263 1164 009 PQ018EF01SZ
IC822 262 2517 908 SN74LV08APW-EL2
IC825 GEN6627 SUB CPU SUB ASS’Y M30620FCPGP(3805-S) *
IC826 262 2557 900 SN74LV14APW-EL2
IC828 GEN6629 PLD SUB ASS’Y EPM3128ATC100-10 *
TR201-204 273 0460 905 KTC2875B-RTK
TR503 269 0192 902 KRC102S-RTK(10K-10K)
TR504 269 0184 907 KRA102S-RTK
TR505-512 269 0192 902 KRC102S-RTK(10K-10K)
TR513-516 269 0184 907 KRA102S-RTK
TR517,518 273 0460 905 KTC2875B-RTK
TR519 269 0192 902 KRC102S-RTK(10K-10K)
TR520 269 0184 907 KRA102S-RTK

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
