Denon AVR-3805 Service Manual

69
69
AVR-3805 / AVC-3890
CAPACITORS GROUP
C301 257 0516 954 CK73B1E104KT
C302 257 0509 929 CK73B1H102KT
C303 257 0516 954 CK73B1E104KT
C304 257 0509 929 CK73B1H102KT
C305 257 0516 954 CK73B1E104KT
C306 257 0509 929 CK73B1H102KT
C307 257 0516 954 CK73B1E104KT
C308 257 0509 929 CK73B1H102KT
C310 254 4603 916 CE67W1E100MT(P.CAP)
C311 257 0516 954 CK73B1E104KT
C312,313 257 0509 929 CK73B1H102KT
C314,315 257 0516 954 CK73B1E104KT
C316,317 257 0509 929 CK73B1H102KT
C318 257 0516 954 CK73B1E104KT
C319 257 0509 929 CK73B1H102KT
C320 257 0516 954 CK73B1E104KT
C321 254 4603 916 CE67W1E100MT(P.CAP)
C322 257 0516 954 CK73B1E104KT
C323-325 257 0509 929 CK73B1H102KT
C326-328 257 0516 954 CK73B1E104KT
C329,330 257 0509 929 CK73B1H102KT
C331 257 0516 954 CK73B1E104KT
C332 254 4601 918 CE67W0J471MT(P.CAP)
C334 257 0516 954 CK73B1E104KT
C335 257 0509 929 CK73B1H102KT
C336 257 0516 954 CK73B1E104KT
C337 257 0509 929 CK73B1H102KT
C338 257 0516 954 CK73B1E104KT
C339 257 0509 929 CK73B1H102KT
C340 257 0516 954 CK73B1E104KT
C341,342 257 0509 929 CK73B1H102KT
C343 257 0516 954 CK73B1E104KT
C344 257 0509 929 CK73B1H102KT
C345,346 257 0516 954 CK73B1E104KT
C347 257 0509 929 CK73B1H102KT
C348 257 0516 954 CK73B1E104KT
C349 257 0509 929 CK73B1H102KT
C350 257 0516 954 CK73B1E104KT
C351 257 0509 929 CK73B1H102KT
C352 257 0516 954 CK73B1E104KT
C353 257 0509 929 CK73B1H102KT
C356 254 4601 918 CE67W0J471MT(P.CAP)
C359,360 257 0501 927 CK73B1H153KT
OTHER PARTS GROUP
CW261,262 205 1247 917 26P SOCKET(9142)-SMT *
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
