Page #101 background image
101
101
AVR-3805 / AVC-3890
52 412 4995 013 RADIATOR BRACKET (R) 1
53 412 4296 107 RADIATOR BRACKET 1
! 54 233 6467 001 POWER TRANS(3805EU) for EU,EC,EUT 1 *
! 54 233 6468 000 POWER TRANS(3805E2) for E2,E2A 1 *
! 54 233 6469 009 POWER TRANS(3805E1C) for E1C,E1K 1 *
! 54 233 0671 000 POWER TRANS(3805-N) for JP 1 *
58 143 1193 006 WINDOW for EU black model,EC,E1C,EUT,E1K 1 *
58 143 1193 019 WINDOW for EU silver model 1 *
58 143 1193 022 WINDOW for E2 black model,E2A 1 *
58 143 1193 035 WINDOW for E2 silver model 1 *
58 143 1193 064 WINDOW for JP 1 *
59 146 2350 009 INNER FRAME ASS'Y for EU black model,EC 1 *
59 146 2350 012 INNER FRAME ASS'Y for EU silver model 1 *
59 146 2350 025 INNER FRAME ASS'Y for E2 black model 1 *
59 146 2350 038 INNER FRAME ASS'Y for E2 silver model 1 *
59 146 2350 041 INNER FRAME ASS'Y for gold model 1 *
60 461 1182 009 RUBBER SHEET 2 *
61 461 1182 012 RUBBER SHEET 2 *
62 113 1996 105 CURSOR KNOB for black model 1 *
62 113 1996 118 CURSOR KNOB for silver model 1 *
62 113 1996 121 CURSOR KNOB for gold model 1 *
64 461 0635 052 SPACER RUBBER 2
65 461 0573 033 RUBBER SHEET 1
66 113 1995 009 ENTER KNOB for black model 1 *
66 113 1995 012 ENTER KNOB for silver model 1 *
66 113 1995 025 ENTER KNOB for gold model 1 *
67 144 2875 106 DOOR ASS'Y for black model 1 *
67 144 2875 119 DOOR ASS'Y for silver model 1 *
67 144 2875 122 DOOR ASS'Y for gold model 1 *
68 102 0671 007 TOP COVER for black model 1 *
68 102 0671 010 TOP COVER for silver model 1 *
68 102 0671 023 TOP COVER for gold model 1 *
69 441 1945 019 PLATE (T/C) 1
70 102 0662 003 TOP PLATE for JP 1
72 461 0573 088 RUBBER SHEET for E2,E2A,JP 2
73 461 1017 035 RUBBER SHEET for E2,E2A 2
73 461 0573 091 RUBBER SHEET for JP 2
74 401 0195 105 HINGE (L) for black model 1 *
74 401 0195 118 HINGE (L) for silver model 1 *
74 401 0195 121 HINGE (L) for gold model 1 *
75 401 0196 104 HINGE (R) for black model 1 *
75 401 0196 117 HINGE (R) for silver model 1 *
75 401 0196 120 HINGE (R) for gold model 1 *
76 412 5083 102 DOOR STOPPER 1 *
77 112 0929 002 KNOB (M) ASS'Y for black model 1 *
77 112 0929 015 KNOB (M) ASS'Y for silver model 1 *
77 112 0929 028 KNOB (M) ASS'Y for gold model 1 *
78 112 0931 003 KNOB (F) ASS'Y for black model 1 *
78 112 0931 016 KNOB (F) ASS'Y for silver model 1 *
78 112 0931 029 KNOB (F) ASS'Y for gold model 1 *
79 113 1994 107 P.KNOB ASS'Y(MAIN) for black model 1 *
79 113 1994 110 P.KNOB ASS'Y(MAIN) for silver model 1 *
79 113 1994 123 P.KNOB ASS'Y(MAIN) for gold model 1 *
80 113 1992 109 P.KNOB ASS'Y(SUB) for black model 1 *
80 113 1992 112 P.KNOB ASS'Y(SUB) for silver model 1 *
80 113 1992 125 P.KNOB ASS'Y(SUB) for gold model 1 *
81 412 5082 006 SUPPORT PLATE 1 *
82 461 1186 005 SPACER 1 *
83 1462348008 FLD HOLDER AS701 1
84 421 0763 010 GEAR DAMPER 1 *
85 461 1187 004 H/P PLATE 1 *
Ref. No. Part No. Part Name Remarks Q'ty New
