Denon AVR-3805 Service Manual

102
102
AVR-3805 / AVC-3890
86 479 0003 038 PUSH RIVET 1
87 146 2361 001 SCREW COVER 1 *
88 461 1133 003 EMI GASKET UC300279 1/10
★
009 0151 011 15P FFC CABLE(1.25) for EU,EC,E2,E2A,E1C,EUT,E1K 1
★
445 8004 007 WIRE CLAMPER 11
★
203 5298 018 3P VH CON. CORD for E2,E2A 1
★
204 2949 004 10P PH-PH CON.CORD 1
★
204 0570 006 6P PH-PH SHIELD CORD 1
★
415 0767 053 UL TUBE (11.1) BK 1
★
445 8004 007 WIRE CLAMPER for E2,E2A 1
★
445 0048 016 CORD HOLDER (L50) 2
★
125 0092 016 BUTYL TAPE (W=25) for E2,E2A,JP 1/33
★
125 0096 012 NITOFLON TAPE(W25) for E2,E2A,JP 1/66
★
125 0092 029 BUTYL TAPE (W=15) for E2,E2A,JP 1/45
★
513 3858 001 FUSE CAUTION LABEL for EU,EC 1
★
513 3333 005 LABEL (TRANS) 1
★
GEN6560 LICENSE SUB ASS'Y for EU,EC,E2,E2A,E1C,EUT,E1K 1 *
★
GEN6560-1 LICENSE SUB ASS'Y for JP 1 *
★
113 1945 004 RJ45 DUST COVER 1
★
415 0845 001 SP RIVET for E2,E2A,E1C,E1K 18
★
GEN6126-6 RATING LABEL (K) for E1K 1 *
★
GEN6071H6 RATING LABEL (T) for EUT 1 *
★
513 3745 004 EMI LABEL (KOREA) for E1K 1
★
203 5177 058 3P VH CON. CORD for EU,EC,E1C,EUT,E1K 1 *
★
203 5177 045 3P VH CON. CORD for E2,E2A,JP 1 *
★
203 5330 002 3P VH-VH CON. CORD 1 *
★
203 6604 009 4P PH-PH CON. CORD 1 *
★
203 5329 000 3P PH-PH CON. CORD 1 *
★
203 5326 003 3P PH-PH CON. CORD 1 *
★
203 5327 002 3P PH-PH CON. CORD 1 *
★
203 5328 001 3P PH-PH CON. CORD 1 *
★
009 0246 007 30P FFC CABLE 1 *
★
204 2546 070 8P KR-KR RIBBON 200 1 *
★
415 0790 091 UL TUBE (14.3) BK 1 *
SCREWS
101 471 8010 100 SPECIAL SCREW 1
102 473 7002 005 3X6 CBTS(S)-Z 8
103 473 7002 018 3X8 CBTS (S)-Z for EU,EC,EUT,JP 16
103 473 7002 018 3X8 CBTS (S)-Z for E2,E2A,E1C,E1K 18
104 473 7003 017 3X8 CFTS (S)-B 2
105 473 7004 016 4X6 CBTS (S)-Z 8
106 473 7015 018 3X8 CBTS (S)-B for EU,EC,EUT 15
106 473 7015 018 3X8 CBTS (S)-B for E2,E2A,E1C,E1K 16
106 473 7015 018 3X8 CBTS (S)-B for JP 12
107 473 7500 015 3X8 CBTS (P)-Z 37
108 473 7500 028 3X8 CFTS (P)-Z 9
109 473 7501 001 3X10 CBTS (P)-Z 4
110 473 7501 030 3X20 CBTS (P)-Z 3
111 473 8034 056 3X14 CBTS(B)Z 9
112 473 8034 098 3X10 CBTS(B)-B for EU,EC,E2,E2A,E1C,EUT,E1K 4
112 473 8034 098 3X10 CBTS(B)-B for JP 10
113 473 8064 000 4X8 CBTS(B)-B-3P for black model 6
113 473 8064 013 4X8 CBTS(B)-N-3P for silver model, gold model 6
115 477 0064 107 FIXING SCREW for EU,EC,EUT 46
115 477 0064 107 FIXING SCREW for E2,E2A,E1C,E1K 44
115 477 0064 107 FIXING SCREW for JP 41
116 477 0153 018 3X16 CPTS(B) SW W 14
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
