Denon AVR-3805 Service Manual

88
88
AVR-3805 / AVC-3890
R468 247 2018 903 RM73B--0R0KT
R471,472 247 2004 920 RM73B--470JT
R473 247 2007 956 RM73B--112JT
R474 247 2009 983 RM73B--103JT
R475 247 2005 903 RM73B--101JT
R482 247 2018 903 RM73B--0R0KT
R483 247 2003 934 RM73B--200JT
R487 247 2018 903 RM73B--0R0KT
R488 247 2009 967 RM73B--822JT
R489 247 2009 983 RM73B--103JT
R490,491 247 2006 915 RM73B--271JT
R503 247 2004 975 RM73B--750JT
R504 247 2005 945 RM73B--151JT
R505 247 2004 975 RM73B--750JT
R506 247 2005 945 RM73B--151JT
R507 247 2004 975 RM73B--750JT
R508 247 2005 945 RM73B--151JT
R509 247 2004 975 RM73B--750JT
R510 247 2005 945 RM73B--151JT
R511-516 247 2010 969 RM73B--223JT
R517-522 247 2004 975 RM73B--750JT
R524-527 247 2005 945 RM73B--151JT
R529,530 247 2008 913 RM73B--202JT
R533,534 247 2009 983 RM73B--103JT
R535,536 247 2005 903 RM73B--101JT
R537,538 247 2008 913 RM73B--202JT
R541,542 247 2009 983 RM73B--103JT
R543,544 247 2005 903 RM73B--101JT
R545 247 2006 960 RM73B--471JT
R546 247 2006 986 RM73B--561JT
R547,548 247 2006 960 RM73B--471JT
R549,550 247 2009 983 RM73B--103JT
R551-554 247 2005 903 RM73B--101JT
R555,556 247 2009 983 RM73B--103JT
R557 247 2006 973 RM73B--511JT
R558 247 2006 960 RM73B--471JT
R559 247 2006 999 RM73B--621JT
R560 247 2006 986 RM73B--561JT
R561 247 2004 975 RM73B--750JT
R562 247 2005 945 RM73B--151JT
R563,564 247 2004 920 RM73B--470JT
R565,566 247 2006 986 RM73B--561JT
R567 247 2004 975 RM73B--750JT
R568 247 2005 945 RM73B--151JT
R569,570 247 2006 960 RM73B--471JT
R571,572 247 2009 983 RM73B--103JT
R573,574 247 2005 903 RM73B--101JT
R583 247 2009 967 RM73B--822JT
R584 247 2007 969 RM73B--122JT
R585 247 2011 942 RM73B--473JT
R586 244 2052 960 RS14B3A221JNBST(S)
R587 247 2009 967 RM73B--822JT
R590,591 247 2009 909 RM73B--472JT (1608)
R592 247 2007 943 RM73B--102JT
R595,596 247 2005 945 RM73B--151JT
R601 247 0012 927 RM73B--104JT
R602 247 0009 985 RM73B--103JT
R603 247 0010 932 RM73B--163JT
R604 247 2007 943 RM73B--102JT
R605 247 2001 981 RM73B--4R7KT
R606 247 2012 925 RM73B--104JT
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
