Denon AVR-3805 Service Manual

92
92
AVR-3805 / AVC-3890
ST102 205 0452 017 STYLE PIN
TP601 205 0154 030 3P NH CONNECTOR BASE
W701,702 205 1034 007 M3 SCREW TERMINAL
W708,709 205 1034 010 M3 SCREW TERMINAL
W716 203 0729 003 1P CONTACT ASS'Y *
W742 001 0234 015 VINYL WIRE *
X451 399 0739 006 X'TAL(14.32M-RIBER)
X452 399 0105 009 CSB503F2
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
