Denon AVR-3805 Service Manual

94
94
AVR-3805 / AVC-3890
TR739 269 0193 901 KRC104S-RTK(47K-47K)
TR740 269 0191 903 KRA104S-RTK(47K-47K)
TR741 269 0048 904 DTC143EK-T96
TR742 269 0191 903 KRA104S-RTK(47K-47K)
TR743 269 0193 901 KRC104S-RTK(47K-47K)
TR744 269 0191 903 KRA104S-RTK(47K-47K)
TR745 269 0193 901 KRC104S-RTK(47K-47K)
TR746 269 0191 903 KRA104S-RTK(47K-47K)
TR747 269 0193 901 KRC104S-RTK(47K-47K)
TR748 269 0191 903 KRA104S-RTK(47K-47K)
TR749 269 0193 901 KRC104S-RTK(47K-47K)
TR750 269 0191 903 KRA104S-RTK(47K-47K)
TR751 269 0193 901 KRC104S-RTK(47K-47K)
TR752 269 0191 903 KRA104S-RTK(47K-47K)
TR753 271 0316 901 KTA1042D *
TR754 269 0191 903 KRA104S-RTK(47K-47K)
D101 276 0773 905 RB501V-40
D701-726 276 0794 900 KDS160 *
D727 276 0704 903 1SR35-400A(T93X)
ZD701 276 0468 906 HZS9B-1TD
ZD702 276 0683 956 UDZS15B-TE17
ZD703 276 0683 998 UDZS16B-TE17
RESISTORS GROUP
R101-104 247 2002 964 RM73B--100JT
R105 247 2006 960 RM73B--471JT
R107 247 2006 960 RM73B--471JT
R109 247 2008 913 RM73B--202JT
R111 247 2008 913 RM73B--202JT
R113,114 247 2006 973 RM73B--511JT
R117,118 247 2005 903 RM73B--101JT
R119,120 247 2007 943 RM73B--102JT
R121,122 247 2002 964 RM73B--100JT
R123,124 247 2007 927 RM73B--821JT
R125 247 2008 913 RM73B--202JT
R127 247 2008 913 RM73B--202JT
R131,132 247 2009 983 RM73B--103JT
R133,134 247 2005 903 RM73B--101JT
R136,137 247 2009 983 RM73B--103JT
R139 247 2008 942 RM73B--272JT
R140 247 2006 902 RM73B--331JT (1608)
R141 247 2009 941 RM73B--682JT
R142,143 247 2008 926 RM73B--222JT
R144 247 2010 998 RM73B--303JT
R145,146 247 2018 903 RM73B--0R0KT
R147,148 247 2009 983 RM73B--103JT
R149 247 2008 955 RM73B--302JT
R150 247 2006 931 RM73B--361JT
R151,152 247 2018 903 RM73B--0R0KT
R153 247 2006 973 RM73B--511JT
R156 247 2009 912 RM73B--512JT
R157 247 2009 967 RM73B--822JT
R158 247 2006 986 RM73B--561JT
R159,160 247 2007 943 RM73B--102JT
R161 247 2005 903 RM73B--101JT
R162 247 2007 956 RM73B--112JT
Ref. No. Part No. Part Name Remarks New
